Panduit PUR6C04OR-U - The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), Orange jacket. Packaged 1000 ft./305m in an easy payout carton.
Panduit

PUR6C04OR-U

UPC: 074983220977

Documents & Media
BrochureSpecification Sheet

Contact for Pricing

Minimum Qty: 1000

Multiplier: 36000

*Contact for lower quantities*

Overview

The Panduit TX6 Cat 6 U/UTP Riser Cable (SKU: PUR6C04OR-U) delivers reliable Gigabit Ethernet performance with 23 AWG solid copper conductors, HDPE insulation, and a flame-retardant PVC (CMR) jacket. Designed for commercial and industrial riser applications, this cable supports Category 6 performance standards, ensuring high-speed data transfer up to 1 Gbps at 250 MHz. Each of the four twisted pairs is separated by a cross divider to minimize crosstalk and alien crosstalk, maintaining signal integrity in high-density installations. The orange CMR-rated jacket provides clear identification and meets fire safety standards for vertical riser applications. Packaged in a 1000 ft. (305m) easy-payout carton, this cable simplifies bulk installation in data centers, office buildings, and industrial facilities. Compatible with standard Cat 6 patch panels, keystone jacks, and connectors, it integrates seamlessly with existing structured cabling systems. The solid copper construction ensures long-term durability and consistent performance, while the flame-retardant PVC jacket enhances safety in plenum and riser environments.
  • 23 AWG solid copper conductors for reliable signal transmission
  • HDPE insulation and cross divider to minimize crosstalk
  • Flame-retardant PVC (CMR) jacket meets riser fire safety standards
  • Supports Category 6 performance up to 1 Gbps at 250 MHz
  • 1000 ft. (305m) easy-payout carton for efficient bulk installation

Specifications

Color
Orange
Conductor Material
Copper
Construction
U/UTP
Jacket Material
PVC
Jacket Material
Polyvinyl Chloride (PVC)
Material
PVC (CMR), HDPE, Copper
Material
Copper with HDPE insulation and flame-retardant PVC (CMR) jacket
Number Of Conductors
4
Outside Diameter
NA In.
Series
TX6 Cat 6 U/UTP Riser
Size
23 AWG
Temperature Rating
NA F
Type
Bulk Copper Cable
Voltage Rating
NA V
Package Dimensions (L x W x H)
44 IN x 48 IN x 51 IN
Package Weight (Imperial)
1046.88 lbs
The TX6A Cat 6A F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a flame retardant PVC (CMR), Orange jacket. Packaged 1000ft/305m on a reel

PFR6X04OR-CG

The TX6A Cat 6A F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a flame retardant PVC (CMR), Orange jacket. Packaged 1000ft/305m on a reel
The TX6A Cat 6A U/FTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP insulation. The copper conductors are individually shielded, twisted in pairs and covered by a flame retardant PVC (CMP), Orange jacket. Packaged 1000ft/305m on a reel

PUFP6X04OR-UG

The TX6A Cat 6A U/FTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP insulation. The copper conductors are individually shielded, twisted in pairs and covered by a flame retardant PVC (CMP), Orange jacket. Packaged 1000ft/305m on a reel
The TX6000 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), Orange jacket. Packaged 1000 ft./305m in an easy payout carton.

PUR6004OR-W

The TX6000 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), Orange jacket. Packaged 1000 ft./305m in an easy payout carton.
The TX5e Cat 5e U/UTP Plenum copper cable is constructed of 24 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMP), Orange jacket. Packaged 1000 ft./305m in an easy payout carton.

PUP5C04OR-U

The TX5e Cat 5e U/UTP Plenum copper cable is constructed of 24 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMP), Orange jacket. Packaged 1000 ft./305m in an easy payout carton.
Class 4 Copper Cable, Fault Managed Power Systems, 3-Pair, 16/19 AWG, Unshielded, CMP, CL4P, Orange, 2000ft/610m reel
