Contact for Pricing
Minimum Qty: 12000
Multiplier: 1000
*Contact for lower quantities*
Overview
- 23 AWG copper conductors for reliable signal transmission
- FEP/polyolefin (CMP) insulation for plenum-rated applications
- Low smoke and flame-retardant properties for enhanced safety
- Twisted pair construction minimizes crosstalk and EMI
- White jacket for easy identification in plenum spaces
Specifications
Color | White |
Environmental Conditions | Indoor |
Type | Bulk Copper Cable |
Package Dimensions (L x W x H) | 44 IN x 48 IN x 51 IN |
Package Weight (Imperial) | 1010.98 lbs |
PFY6X04WH-CED
The TX6A Cat 6A F/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a HDPE flame retardant (LSZH), White jacket. Packaged 1640ft/500m on a reel
NK688MAW
The NetKey Cat 6 UTP RJ45 Punchdown Keystone Jack Module is designed to terminate 4-pair, 22-26 AWG twisted pair cable. Each module is 100% factory tested to exceed industry standard performance requirements. Contacts are plated with 50 microinches of gold for superior performance. Jack modules are individually serialized for traceability and are compatible with keystone interfaces including NetKey Faceplates, Modular Patch Panels, and Surface Mount Boxes. This jack module is arctic white.
CIDWH-C
Icon with data image, snaps in to jack modules and select faceplates. Package includes 100 white icons (5 runners with 20 icons each)
PR2VD08WH
The PatchRunner 2 Vertical Cable Manager combines high-density capability and versatility, freeing up valuable floor space. The fully pre-assembled manager lowers overall costs. The dual-sided manager has a metal backbone with molded plastic fingers, and includes two full-length metal, dual-hinging, push-to-close doors. The manager is 45 RU, 8 inches wide, and is white.
PE2VSD0696WH
The PatchRunner 2 Enhanced Vertical Cable Manager pairs ultra-high-density capability and versatility with its unique zero RU patching feature. The partially assembled manager installs easily to speed up deployment. The dual-sided manager has a metal backbone with molded plastic fingers, and includes one full-length metal, dual-hinging, push-to-close door. The manager is 52 RU, 6 inches wide, 6 bonus vertical RU, and is white.
PUR6AV04WH-G
The TX6A Vari-MaTriX Cat 6A U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs, separated by a cross divider. All four pairs shall be surrounded by a metallic Vari-MaTriX tape cut into segments of varying length and covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel.
CUEORF06DPW1
The Net-Contain End of Row Kit is used with the Universal Aisle Containment Drop Away Roof Panels. The End of Row Kit is for a 6-foot (1800mm) aisle, and can extend up to four inches. It is white.
CJ588WHY
The Mini-Com Cat 5e UTP RJ45 Leadframe Jack Module is designed to terminate 4-pair, 22-24 AWG twisted pair cable. Each module is 100% factory tested for continuity. Contacts are plated with 50 microinches of gold for superior performance. Jack modules are compatible with Mini-Com Modular Patch Panels and Faceplates. The jack module is White.Frequently Asked Questions
What standards does this cable comply with?
The cable complies with ANSI/TIA-568-2.D Category 6 and ISO 11801 Class E standards.
Is this cable compatible with PoE applications?
Yes, the cable meets IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt for PoE applications.
What is the maximum operating voltage?
The maximum operating voltage for the cable is 80V.
What is the maximum installation tension?
The maximum installation tension is 25 lbf (110N).
What types of Ethernet does this cable support?
The cable supports Ethernet 10BASE-T, 100BASE-T, 1000BASE-T, and 10GBASE-T.
What is the temperature range for installation?
The installation temperature range is 32°F to 122°F (0°C to 50°C).
What is the operating temperature range?
The operating temperature range is -4°F to 194°F (-20°C to 90°C).
What is the cable construction type?
The cable is constructed with 23 AWG solid copper conductors covered by FEP/polyolefin insulation.
What is the cable's diameter?
The nominal diameter of the cable is 0.205 in. (5.2mm).
What is the weight of the cable per 1000 ft?
The cable weighs 25 lbs. per 1000 ft. (12 kg/305m).
How to Install the REELEX® System Packaging
This guide provides step-by-step instructions for properly installing and handling the REELEX® System Packaging to ensure optimal performance and prevent tangling.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers
Supplies needed:
Mounting screws, Terminal connectors
- Orient the package
Ensure that the package is oriented with the payout hole facing the direction from which the product will be pulled. Keep the coil upright to prevent tangling.
- Secure the package
Place the package on a pallet with the coils upright. Ensure that the paperboard flute direction is vertical when stacked to provide support and prevent crushing.
- Resolve tangles
If a tangle occurs, access the inside of the coil through the access panel or by opening the package. Carefully thread the inside end back through the payout tube to resolve the issue.
