Contact for Pricing
Minimum Qty: 20000
Multiplier: 1000
*Contact for lower quantities*
Overview
- 23 AWG copper conductors for reliable data transmission
- FEP/polyolefin insulation for signal integrity
- Overall metallic shield protects against EMI/RFI
- Flame-retardant PVC (CMP) jacket for plenum spaces
- 1000 ft (305m) reel for efficient installation
Specifications
Color | Red |
Conductor Material | Copper |
Construction | F/UTP |
Jacket Material | PVC |
Jacket Material | Polyvinyl Chloride (PVC) |
Material | Copper, FEP/polyolefin, metallic shield, PVC (CMP) |
Number Of Conductors | 4 |
Outside Diameter | NA In. |
Series | TX6 Cat 6 F/UTP Plenum |
Size | 23 AWG |
Temperature Rating | NA F |
Type | Bulk Copper Cable |
Voltage Rating | NA V |
Package Dimensions (L x W x H) | 44 IN x 48 IN x 51 IN |
Package Weight (Imperial) | 950 lbs |
PUP6AHD04RD-G
The TX6A Vari-MaTriX HD Cat 6A U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP insulation. The copper conductors shall be twisted in pairs. All four pairs shall be surrounded by a metallic Vari-MaTriX tape cut into segments of varying length and covered by a flame retardant PVC (CMP), Red jacket. Packaged 1000 ft./305m on a reel.
PFR6X04RD-CG
The TX6A Cat 6A F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a flame retardant PVC (CMR), Red jacket. Packaged 1000ft/305m on a reel
PUFR6X04RD-UG
The TX6A Cat 6A U/FTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are individually shielded, twisted in pairs and covered by a flame retardant PVC (CMR), Red jacket. Packaged 1000ft/305m on a reel
PUR5C04RD-U
The TX5e Cat 5e U/UTP Riser copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs. All four pairs shall be covered by a flame retardant PVC (CMR), Red jacket. Packaged 1000 ft./305m in an easy payout carton.
PXUP316ARD-UQ
Class 4 Copper Cable, Fault Managed Power Systems, 3-Pair, 16/19 AWG, Unshielded, CMP, CL4P, Red, 2000ft/610m reel
PFR6C04RD-UG
The TX6 Cat 6 F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), Red jacket. Packaged 1000 ft./305m on a reel.
ISFX5502ARD-LED
IndustrialNet Copper Cable, Industrial Ethernet, Category 5e, 2-pair, 24/7 AWG, SF/UTP, Flame retardant, High flex, Oil and ozone resistant, Abrasion resistant, PUR jacket, Red, 1640ft/500m reel
PUR6C04RD-F
The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), Red jacket. Packaged 1000 ft./305m in an easy payout carton.
PUR6004RD-UY
The TX6000 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), Red jacket. Packaged 1000 ft./305m on a reel in a box.
PUP6504RD-UY
The TX6500 Cat 6 U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMP), Red jacket. Packaged 1000 ft./305m on a reel in a box.
Frequently Asked Questions
Are there other color options available for PFP6C04RD-UG cable?
Yes, customers can contact Panduit customer service for more color options for Mini-Com shielded copper cables.
What type of cable is PFP6C04RD-UG?
The PFP6C04RD-UG is a Category 6 F/UTP Riser Copper Cable, part of the Mini-Com® Shielded System.
What Mini-Com shielded jack modules are compatible with Category 6 cable?
Compatible Mini-Com shielded jack modules for Category 6 include standard (CJS688TG^Y) and shuttered (CJSH688TG^Y) types.
What warranty is offered with an end-to-end Mini-Com Solution?
An end-to-end Mini-Com Solution receives a 25-year system warranty.
Does Panduit Category 6 cabling support Power over Ethernet?
Yes, Panduit's Category 6 solutions support PoE, PoE+, and PoE++.
What is the cable bandwidth for Panduit Category 6 solutions?
Panduit's quality Category 6 cable technology offers 550 MHz bandwidth. Enhanced Category 6 systems provide 650 MHz cable bandwidth.
What applications does Panduit copper cabling support?
Panduit copper cabling supports Power over Ethernet, wireless connectivity, intelligent lighting, security cameras, audio/visual, and building automation systems.
What is the highest operating temperature for Category 6A Vari-MaTriX connectors?
Category 6A Vari-MaTriX connectors have a highest operating temperature of 75° C.
What is the highest operating temperature for Category 6A Vari-MaTriX cable?
Category 6A Vari-MaTriX cable has a highest operating temperature of 105° C.
What warranty does an end-to-end Mini-Com solution offer?
An end-to-end Mini-Com Solution receives a 25-year system warranty.
