Contact for Pricing
Minimum Qty: 100
Multiplier: 1
*Contact for lower quantities*
Overview
- One-hole lug for secure mounting
- Accommodates 4-6mm² metric conductors
- Compatible with M8 stud holes
- Standard barrel with window lug for visual inspection
- Designed for industrial electrical applications
Specifications
Amperage Rating | NA A |
Angle* | Straight |
Material | Tin-plated Copper |
Number Of Holes | NA |
Special Features | Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
Standard | Meets EN 61238-1:2003/IEC 61238-1:2003 Class B WITH Class 2r Wire, UKCA compliant, CE compliant |
Type | Tin-Plated CopperCompression Connectors - Metric Lugs |
Voltage Rating | NA V |
Package Dimensions (L x W x H) | 4.8 IN x 3.5 IN x 3.5 IN |
Package Weight (Imperial) | 0.5 lbs |
