Overview
- One-hole metric conductor lug for secure electrical terminations
- Standard barrel with window for visual inspection of conductor insertion
- Accommodates 150mm wire size for versatile applications
- Designed for M20 stud hole compatibility
- Manufactured by Panduit to meet industry safety and performance standards
Specifications
Amperage Rating | NA A |
Angle* | Straight |
Barrel Type* | Standard Barrel Length with Inspection Window |
Connection Type | Window Lug (screw terminal) |
Connection Type | One-Hole Lug |
Connection Type | Lug |
Connection Type | Window Lug |
Connection Type | Compression Lug |
Current Rating | 150 A |
Material | Copper |
Material | Metal (Lug) |
Material | Tin-plated Copper |
Material | Metal |
Mounting Type | One-Hole |
Mounting Type | One-hole, M20 stud |
Mounting Type | One-hole, metric conductor |
Mounting Type | One-hole metric |
Number Of Holes | NA |
Series | LCMA |
Size | 150mm |
Size | 150mm wire, M20 stud hole |
Size | 150mm wire |
Special Features | Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
Standard | Meets EN 61238-1:2003/IEC 61238-1:2003 Class B WITH Class 2r Wire, UKCA compliant, CE compliant |
Type | Tin-Plated CopperCompression Connectors - Metric Lugs |
Voltage Rating | NA V |
