Panduit LCD10-10A-L - The LCD10-10A-L Tin-Plated Copper Compression Lug, two-hole, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified to 35 KV and temperature rated to 90 C.
Panduit

LCD10-10A-L

UPC: 074983972159

Documents & Media
Technical BulletinTechnical DrawingFull Engineering DrawingInstallation InstructionsVideo Clip

Contact for Pricing

Overview

The Panduit LCD10-10A-L is a tin-plated copper compression lug designed for reliable electrical connections in high-voltage applications. This two-hole, standard barrel lug is manufactured by Panduit (SKU: LCD10-10A-L) and is UL Listed and CSA Certified to 35 kV, ensuring compliance with stringent safety standards. Its construction from high-conductivity copper with a tin-plated finish provides excellent conductivity and corrosion resistance, crucial for longevity in industrial environments. The barrel is color-coded and marked with Panduit and specified competitor die index numbers, facilitating accurate crimp die selection for consistent, low-resistance terminations. An integrated inspection window allows for visual verification of full conductor insertion, minimizing installation errors and enhancing safety. This lug is rated for continuous operation at 90°C, making it suitable for demanding power distribution, switchgear, and renewable energy system applications. It is designed for use with standard copper conductors, delivering durable connections essential for high-current circuits. The lug features a 10 AWG copper conductor size, a 1/4" (6.4 mm) stud hole size, and a 5/8" (16 mm) stud hole spacing. The tongue width is 0.6" (15.3 mm), tongue thickness is 0.1" (2.6 mm), barrel length is 0.88" (22.4 mm), and overall length is 2.4" (61 mm). The wire strip length is 15/16" (23.6 mm). The standard package quantity is 25.
  • Tin-plated copper construction for conductivity and corrosion resistance
  • Two-hole, standard barrel design
  • UL Listed and CSA Certified to 35 kV
  • Color-coded barrels with die index numbers for proper crimp selection
  • Inspection window for visual confirmation of conductor insertion

Specifications

Angle*
Straight
Barrel Type*
Standard
Color
Color-coded
Color
Color-coded (Tin-Plated Copper)
Connection Type
Compression Lug
Current Rating
10 A
Material
Tin-plated Copper
Mounting
7/16 In.
Mounting Type
Crimp
Mounting Type
Two-Hole
Mounting Type
Two-hole, standard barrel
Number Of Holes
2
Poles
2
Series
LCD
Size
#10 AWG wire
Size
Size 10A
Size
Two-hole, standard barrel
Size
#14 — #10 AWG Code STR, #12 — #10 AWG Code SOL
Size
#14 #10 AWG Code STR, #12 #10 AWG Code SOL
Size
10 AWG
Special Features
Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Standard
CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, NEBS Level 3
Stud Size
#10 In.
Type
Compression Lug
Voltage Rating
35 kV
Package Dimensions (L x W x H)
4.05 IN x 2.05 IN x 1.35 IN
Package Weight (Imperial)
0.635 lbs
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.

AS-K1-H6

Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

How to Install Copper Compression Connectors

This guide provides step-by-step instructions for properly installing copper compression connectors, ensuring secure and reliable electrical connections.

Estimated time: 30m

Tools needed:

Wire strippers, Crimping tool, Multimeter

Supplies needed:

Copper compression connectors, Wire

  1. Select the appropriate connector

    Choose a connector that matches the wire size and material. Ensure you do not use a copper connector on aluminum wire.

  2. Prepare the wire

    Strip the wire insulation to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.

  3. Insert and crimp the connector

    Insert the stripped wire into the connector until it stops. Use the crimping tool to crimp the connector between the color bands or knurl markings, starting near the tongue end and moving towards the wire end.

  4. Inspect the crimp

    After crimping, check for any sharp edges, flash, or burrs on the connector and remove them if present.
