Panduit LCCN350-38DW-6 - The LCCN350-38DW-6 Tin Plated Copper Compression Lug, two-hole, long barrel, narrow tongue has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. The long barrel maximizes the number of crimps and provides premium wire pull-out strength and performance. An inspection window aids to visually assure full conductor insertion. UL Listed and CSA Certified to 35 KV and temperature rated to 90 C.
Panduit

LCCN350-38DW-6

UPC: 613056853263

Documents & Media
Technical BulletinTechnical DrawingFull Engineering DrawingInstallation Instructions

Contact for Pricing

Minimum Qty: 30

Multiplier: 6

*Contact for lower quantities*

Overview

The Panduit LCCN350-38DW-6 Tin Plated Copper Compression Lug is a high-performance, two-hole, long-barrel compression lug designed for 350 kcmil stranded copper conductors. This UL Listed and CSA Certified lug (to 35 kV) features a narrow tongue with a 3/8" (9.5 mm) stud hole and 1.28" (32.5 mm) hole spacing, ensuring compatibility with standard mounting hardware. The long barrel design maximizes crimp points, delivering superior wire pull-out strength and mechanical reliability in demanding electrical applications. A built-in inspection window allows for visual confirmation of full conductor insertion before final crimping, reducing installation errors and improving connection integrity. The color-coded barrel (Red) is marked with Panduit’s P71 die index number and competitor die indices (Burndy P71, T&B 12.3125) for tool compatibility, streamlining crimp die selection across multiple brands. Tin-plated copper construction provides corrosion resistance, while the enclosed barrel design prevents corrosive contaminants from entering the connection in harsh environments. Temperature-rated to 90°C, this lug is ideal for power distribution, industrial machinery, and utility applications where long-term reliability and safety compliance are critical. Certified to Telcordia NEBS Level 3 and American Bureau of Shipping standards, the LCCN350-38DW-6 meets rigorous industry requirements for grounding, bonding, and power termination systems.
  • UL Listed and CSA Certified to 35 kV with 90°C temperature rating
  • Two-hole design with 3/8" (9.5 mm) stud hole and 1.28" (32.5 mm) hole spacing
  • Long barrel maximizes crimps for superior wire pull-out strength
  • Inspection window ensures full conductor insertion before crimping
  • Color-coded barrel (Red) with Panduit P71 and competitor die indices for tool compatibility

Specifications

Barrel Type*
Long
Color
Red
Connection Type
Compression Lug
Material
Tin Plated Copper
Mounting
2-5/16 In.
Poles
2
Series
LCCN350
Standard
C22.2 No. 65-13, 486A-486B File #E52164
Stud Size
3/8 In.
Type
Compression Lug
Voltage Rating
35 kV
Package Dimensions (L x W x H)
8.8 IN x 3.4 IN x 3.3 IN
Package Weight (Imperial)
10.8 lbs
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.

AS-K1-H6

Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

How to Install Copper Compression Connectors

This guide provides step-by-step instructions for installing copper compression connectors, ensuring a secure and reliable electrical connection.

Estimated time: 30m

Tools needed:

Wire strippers, Crimping tool, Heat gun or propane torch

Supplies needed:

Copper compression connectors, Heat shrink tubing

  1. Select the correct connector

    Choose a connector that matches the wire size and material. Ensure you do not use copper connectors on aluminum wire.

  2. Strip the wire

    Use wire strippers to remove insulation from the wire to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.

  3. Insert and crimp the connector

    Insert the stripped wire into the connector until it reaches the stop. Use a crimping tool to crimp the connector, following the color bands or knurl markings as a guide for even spacing.

  4. Inspect the crimp

    Check the crimped connector for sharp edges, flash, or burrs and remove any imperfections to ensure a safe connection.

  5. Prepare heat shrink tubing

    Cut the heat shrink tubing to a length that allows for adequate insulation coverage, ensuring at least 1.5 inches of overlap on the wire insulation.

  6. Apply heat shrink

    Position the heat shrink tubing over the crimped connector and apply heat using a heat gun or propane torch, moving from the crimped portion toward the insulated wire until the adhesive flows at the ends.
