Panduit LCC400-12H-6 - Two-hole, long barrel lug, 400 kcmil wire, 1/2 stud hole, 1 3/4 hole spacing, 45 angle tongue.
Panduit

LCC400-12H-6

UPC: 074983902422

Documents & Media
Technical DrawingFull Engineering DrawingInstallation Instructions

Contact for Pricing

Minimum Qty: 6

Multiplier: 1

*Contact for lower quantities*

Overview

The Panduit LCC400-12H-6 is a two-hole, long barrel lug designed for reliable electrical connections. This lug is specifically engineered to accommodate 400 kcmil wire, ensuring robust performance in high-current applications. It features a 1/2 inch stud hole, a standard size for many electrical terminals and busbars, facilitating secure attachment. The hole spacing is precisely set at 1 3/4 inches, which is critical for proper alignment and load distribution when used with multi-hole mounting configurations. A distinctive 45-degree angle tongue is incorporated into the design, offering enhanced accessibility and ease of connection in confined spaces or when routing cables at specific angles. Manufactured in the USA, this lug is built to meet stringent quality standards. Its long barrel design provides increased wire insulation support and a larger surface area for crimping, contributing to a more durable and reliable electrical connection. The LCC400-12H-6 is an essential component for power distribution, industrial machinery, and other heavy-duty electrical installations where dependable wire termination is paramount. Its construction and specifications are optimized for professional electrical work, ensuring safety and efficiency. The UNSPSC code for this product is 39121405, categorizing it within electrical connectors and accessories.
  • Two-hole configuration for secure mounting
  • Long barrel design for enhanced crimp and insulation support
  • Accommodates 400 kcmil wire size
  • 1/2 inch stud hole diameter
  • 1 3/4 inch hole spacing
  • 45 degree angle tongue for improved accessibility

Specifications

Barrel Type*
Long
Color
Blue
Mounting
2-3/8 In.
Mounting Type
Two-hole, 1/2 stud hole
Series
LCC
Size
400 kcmil
Standard
CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, ABS approved, NEBS Level 3
Stud Size
1/2 In.
Type
Compression Lug
Package Dimensions (L x W x H)
7.9 IN x 3.4 IN x 3.4 IN
Package Weight (Imperial)
3.15 lbs
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.

AS-K1-H6

Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

How to Install the LCC400-12H-6 Compression Connectors

This guide provides step-by-step instructions for installing LCC400-12H-6 compression connectors, ensuring secure and reliable electrical connections.

Estimated time: 45m

Tools needed:

Screwdriver, Wire strippers, Crimping tool, Heat gun or propane torch

Supplies needed:

Copper compression connectors, Heat shrink tubing, Wire

  1. Prepare the wire

    Strip the wire insulation to the length specified in the tool chart, ensuring not to nick or damage the conductor strands.

  2. Insert wire into connector

    Insert the stripped wire into the compression connector until it reaches the stop. Ensure a snug fit.

  3. Crimp the connector

    Using the appropriate crimping tool, crimp the connector according to the specified number of compressions indicated in the tool chart. Start crimping near the tongue end and work towards the wire end.

  4. Inspect the crimp

    After crimping, inspect the connector for any sharp edges, flash, or burrs and remove them if present.

  5. Apply heat shrink tubing

    Cut the heat shrink tubing to the desired length, allowing for a minimum of 1.5 inches of overlap on the wire insulation. Slide it over the crimped connector.

  6. Shrink the tubing

    Using a heat gun or propane torch, carefully shrink the tubing starting from the crimped end towards the insulated wire. Ensure adhesive flow at the ends indicates complete shrinkage.
