Overview
- 2000 kcmil copper conductor size
- Two-hole configuration with 1/2" (12.7mm) stud hole size
- 1.75" (44.4mm) hole spacing for versatile mounting
- Long barrel design for enhanced pull-out strength
- UL Listed and CSA certified to 35kV, 90°C rated
Specifications
Barrel Type* | Long |
Color | Brown |
Connection Type | Compression Lug |
Material | Copper |
Mounting | 3-5/8 In. |
Mounting Type | 2-Hole, 1.75" (44.4mm) Hole Spacing |
Series | LCC |
Size | 2000 kcmil |
Standard | CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, ABS approved, NEBS Level 3 |
Stud Size | 1/2 In. |
Type | Compression Lug |
Package Dimensions (L x W x H) | 8 IN x 4 IN x 4 IN |
Package Weight (Imperial) | 3.39 lbs |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install Copper Compression Connectors
This guide provides step-by-step instructions for installing copper compression connectors, ensuring a secure and reliable electrical connection.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Heat gun or propane torch
Supplies needed:
Copper compression connectors, Heat shrink tubing
- Select the correct connector
Choose a connector that matches the wire size and material. Ensure you do not use copper connectors on aluminum wire.
- Strip the wire
Use wire strippers to remove insulation from the wire to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.
- Insert and crimp the connector
Insert the stripped wire into the connector until it reaches the stop. Use a crimping tool to crimp the connector, following the color bands or knurl markings as a guide for even spacing.
- Inspect the crimp
Check the crimped connector for sharp edges, flash, or burrs and remove any imperfections to ensure a safe connection.
- Prepare heat shrink tubing
Cut the heat shrink tubing to a length that allows for adequate insulation coverage, ensuring at least 1.5 inches of overlap on the wire insulation.
- Apply heat shrink
Position the heat shrink tubing over the crimped connector and apply heat using a heat gun or propane torch, moving from the crimped portion toward the insulated wire until the adhesive flows at the ends.
