Panduit LCAX650-38H-6 - One-hole, flex lug, 650 kcmil cable, 3/8 stud hole, 45 angle tongue.
Panduit

LCAX650-38H-6

UPC: 074983447978

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The Panduit LCAX650-38H-6 is a one-hole flex lug specifically engineered for terminating 650 kcmil copper cable. This lug features a 3/8 inch stud hole, designed to accommodate standard mounting hardware, and a 45-degree angled tongue. This angled tongue design is crucial for providing optimal access and alignment during the termination process, ensuring secure and reliable connections within industrial electrical systems. Constructed from high-quality copper, the LCAX650-38H-6 offers excellent electrical conductivity, minimizing resistance and heat buildup, and superior mechanical strength to withstand the rigors of demanding applications. Its one-hole mounting configuration simplifies installation, allowing for straightforward integration into existing infrastructure. The LCAX650-38H-6 is built for dependable performance in critical areas such as power distribution, industrial machinery, and other high-current environments where reliability is paramount. This component is a testament to Panduit's commitment to precision engineering, delivering solutions that enhance system reliability and contribute to operational efficiency. SKU: LCAX650-38H-6. UNSPSC: 39121405. Country of Origin: US.
  • Designed for 650 kcmil copper cable
  • 3/8 inch stud hole for secure mounting
  • 45-degree angled tongue for optimal connection
  • One-hole mounting configuration
  • Durable copper construction for conductivity and strength

Specifications

Angle*
45
Barrel Type*
Standard Barrel Length with Inspection Window
Color
Black
Material
Tin-plated Copper
Mounting
1.5 In.
Number Of Holes
1
Size
646.4 kcmil DLO
Special Features
Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Stud Size
42.95 In.
Type
Tin-Plated Copper Compression Connectors - Lugs
Package Dimensions (L x W x H)
7.8 IN x 4.3 IN x 3.3 IN
Package Weight (Imperial)
3.9 lbs
