Overview
- Designed for 500 kcmil copper cable
- Features a 5/8-inch stud hole
- 90° angle tongue for optimal alignment
- Flex design accommodates cable movement
- Manufactured in the US for reliability
Specifications
Angle* | 90° |
Angle* | 90 |
Barrel Type* | Standard |
Color | Pink |
Connection Type | Flex Lug |
Material | Tin-plated Copper |
Material | Copper |
Material | Metal (likely copper or aluminum) |
Mounting | 1-9/16 In. |
Mounting Type | One-Hole |
Mounting Type | One-hole, 5/8 stud hole |
Mounting Type | One-hole, 5/8" stud hole, 90° angle tongue |
Mounting Type | Stud Hole (5/8 inch) |
Mounting Type | One-hole, 5/8" stud hole |
Mounting Type | 5/8" stud hole with 90° angle tongue |
Mounting Type | 90° angle tongue |
Mounting Type | One-hole, 90° angle tongue |
Number Of Holes | 1 |
Series | LCAX |
Size | 500 kcmil |
Size | 500 kcmil Class G, H, I, K, M and 535.3 kcmil DLO |
Size | 500 kcmil, 5/8" stud hole |
Special Features | Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
Standard | C22.2 No. 65-13, 486A-486B File #E52164, ABS approved |
Stud Size | 5/8 In. |
Type | Compression Lug |
Package Dimensions (L x W x H) | 5.9 IN x 3.4 IN x 3.4 IN |
Package Weight (Imperial) | 4.6 lbs |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install Copper Compression Connectors
This guide provides step-by-step instructions for installing copper compression connectors, ensuring secure and reliable electrical connections.
Estimated time: 30m
Tools needed:
Crimping tool, Wire strippers, Heat gun or propane torch, Multimeter
Supplies needed:
Copper compression connectors, Heat shrink tubing, Wire
- Select the correct connector
Choose a connector that matches the wire size and material. Ensure you do not use a copper connector on aluminum wire.
- Prepare the wire
Strip the wire insulation to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.
- Insert the wire into the connector
Insert the stripped wire into the connector until it reaches the stop. Ensure a snug fit.
- Crimp the connector
Using the appropriate crimping tool and die, crimp the connector starting near the tongue of the lug and working towards the wire entry. Follow the tool chart for the number of crimps required.
- Inspect the crimp
Check the crimped connector for sharp edges, flash, or burrs and remove any imperfections.
- Prepare heat shrink tubing
Cut the heat shrink tubing to the desired length, allowing for at least 1.5 inches of overlap on the wire insulation.
- Apply heat shrink
Use a heat gun or propane torch to shrink the tubing, moving from the crimped portion of the connector towards the insulated wire until adhesive flow indicates completion.
