Panduit LCAX2-14-E - The LCAX2-14-E Tin-Plated Copper Compression Lug, one-hole, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified to 35 KV and temperature rated to 90 C.
Panduit

LCAX2-14-E

UPC: 074983442645

Documents & Media
Technical BulletinTechnical DrawingFull Engineering DrawingInstallation InstructionsVideo Clip

Contact for Pricing

Overview

The Panduit LCAX2-14-E is a tin-plated copper compression lug designed for reliable electrical connections. This one-hole lug features a standard barrel configuration, ensuring compatibility with a wide range of conductors. A key feature for efficient installation and quality control is the color-coded barrel, which is clearly marked with both Panduit and specified competitor die index numbers. This marking system simplifies the selection of the correct crimp die, minimizing errors and ensuring a secure connection. The inclusion of an inspection window allows for visual confirmation of full conductor insertion, a critical step in preventing connection failures. The tin-plated copper construction provides excellent conductivity and helps to inhibit corrosion, extending the lifespan of the connection, especially in challenging environments. This lug is UL Listed and CSA Certified for use in applications up to 35 KV, demonstrating its suitability for high-voltage systems. Furthermore, it is temperature rated to 90°C, making it robust for various operating conditions. Manufactured in the USA, the LCAX2-14-E offers dependable performance for your electrical infrastructure needs.
  • Tin-plated copper construction for corrosion resistance
  • Color-coded barrel with Panduit/competitor die index for easy die selection
  • Inspection window for visual confirmation of conductor insertion
  • UL Listed and CSA Certified to 35 KV
  • Temperature rated to 90°C

Specifications

Angle*
Straight
Barrel Type*
Standard
Color
Brown
Connection Type
Compression Lug
Material
Tin-plated Copper
Mounting
11/16 In.
Number Of Holes
1
Poles
1
Series
LCAX2
Size
#2 AWG Class B, C, G, H, I, K, M and DLO
Size
14 AWG
Special Features
Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Standard
C22.2 No. 65-13, 486A-486B File #E52164, ABS approved
Stud Size
1/4 In.
Type
Compression Lug
Voltage Rating
35kV
Package Dimensions (L x W x H)
4.7 IN x 3.4 IN x 3.4 IN
Package Weight (Imperial)
0.864 lbs
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Non-Insulated Butt Splice, Length 0.63 Inches, Width 0.13 Inches, Wire Range 22-18 AWG, Copper, Tin Plated, 100 Pack

2A-18

Non-Insulated Butt Splice, Length 0.63 Inches, Width 0.13 Inches, Wire Range 22-18 AWG, Copper, Tin Plated, 100 Pack
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

How to Install Copper Compression Connectors

This guide provides step-by-step instructions for installing copper compression connectors, ensuring secure and reliable electrical connections.

Estimated time: 30m

Tools needed:

Crimping tool, Wire strippers, Heat gun or propane torch, Multimeter

Supplies needed:

Copper compression connectors, Heat shrink tubing, Wire

  1. Select the correct connector

    Choose a connector that matches the wire size and material. Ensure you do not use a copper connector on aluminum wire.

  2. Prepare the wire

    Strip the wire insulation to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.

  3. Insert the wire into the connector

    Insert the stripped wire into the connector until it reaches the stop. Ensure a snug fit.

  4. Crimp the connector

    Using the appropriate crimping tool and die, crimp the connector starting near the tongue of the lug and working towards the wire entry. Follow the tool chart for the number of crimps required.

  5. Inspect the crimp

    Check the crimped connector for sharp edges, flash, or burrs and remove any imperfections.

  6. Prepare heat shrink tubing

    Cut the heat shrink tubing to the desired length, allowing for at least 1.5 inches of overlap on the wire insulation.

  7. Apply heat shrink

    Use a heat gun or propane torch to shrink the tubing, moving from the crimped portion of the connector towards the insulated wire until adhesive flow indicates completion.
