Contact for Pricing
Minimum Qty: 10
Multiplier: 1
*Contact for lower quantities*
Overview
- One-hole flex lug for #1 AWG stranded copper conductors
- 3/8" stud hole for secure termination
- 90° angle tongue for installation flexibility in tight spaces
- Constructed from high-strength electrolytic copper for premium performance
- cULus Listed for up to 600V and temperature rated to 90°C
Specifications
Barrel Type* | Standard |
Color | Green |
Mounting | 3/4 In. |
Standard | C22.2 No. 65-13, 486A-486B File #E52164, ABS approved |
Stud Size | 3/8 In. |
Type | Compression Lug |
Package Dimensions (L x W x H) | 4.9 IN x 3.4 IN x 3.4 IN |
Package Weight (Imperial) | 0.827 lbs |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
How to Install Copper Compression Connectors
This guide provides step-by-step instructions for installing copper compression connectors, including crimping and heat shrinking for insulation.
Estimated time: 30m
Tools needed:
Crimping tool, Wire strippers, Heat gun or propane torch
Supplies needed:
Copper compression connectors, Heat shrink tubing
- Select the correct connector
Choose a connector that matches the wire size and material. Ensure you do not use a copper connector on aluminum wire.
- Prepare the wire
Strip the wire insulation to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.
- Insert and crimp the wire
Insert the stripped wire into the connector until it stops. Use the appropriate crimp tool and die as per the tool chart, crimping near the tongue of the lug and working towards the wire entry.
- Inspect the crimp
Check the crimped connector for sharp edges, flash, or burrs and remove any imperfections.
- Prepare heat shrink tubing
Cut the heat shrink tubing to the desired length, allowing for at least 1.5 inches of overlap on the wire insulation.
- Apply heat shrink
Use a heat gun or propane torch to shrink the tubing, moving from the crimped portion of the connector towards the insulated wire until adhesive flow indicates completion.
