Contact for Pricing
Minimum Qty: 10
Multiplier: 1
*Contact for lower quantities*
Overview
- One-hole standard barrel lug for 250 kcmil cable terminations
- 90° angle tongue optimizes cable routing and reduces bend stress
- 5/16" stud hole for secure mounting to bus bars or panels
- Window lug design enables visual inspection without disassembly
- US-manufactured for industrial-grade durability and reliability
Specifications
Barrel Type* | Standard |
Color | Yellow |
Connection Type | Crimp |
Material | Copper Alloy |
Mounting | 1-5/16 In. |
Mounting Type | Stud Hole |
Series | LCA |
Size | 250 kcmil |
Standard | UL Listed to 486A-486B File #E52164, NEBS Level 3, ABS |
Stud Size | 5/16 In. |
Type | Compression Lug |
Package Dimensions (L x W x H) | 4.9 IN x 3.4 IN x 3.4 IN |
Package Weight (Imperial) | 1.33 lbs |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install the LCA250-56F-X Compression Connectors
This guide provides step-by-step instructions for installing and crimping LCA250-56F-X compression connectors for electrical wiring.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Multimeter
Supplies needed:
LCA250-56F-X connectors, Wire, Cleaning cloth
- Prepare the wire
Strip the wire insulation to the appropriate length as indicated in the tool chart. Ensure not to nick or ring the conductor strands.
- Clean the wire
Use a cleaning cloth to remove any dirt or oxidation from the stripped wire to ensure a good electrical connection.
- Insert the wire into the connector
Insert the stripped wire into the LCA250-56F-X connector until the wire stops. Ensure it is fully seated.
- Crimp the connector
Using the appropriate crimping tool, position the connector in the die and crimp it according to the color bands or knurl markings. Start crimping near the tongue end and move towards the wire end.
- Inspect the crimp
After crimping, inspect the connector for sharp edges, flash, or burrs and remove any if present to ensure safety and reliability.
