Panduit LCA2/0-12-X - The LCA2/0-12-X Tin-Plated Copper Compression Lug, one-hole, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified to 35 KV and temperature rated to 90 C.
Panduit

LCA2/0-12-X

UPC: 074983900312

Documents & Media
Technical BulletinTechnical DrawingFull Engineering DrawingInstallation InstructionsVideo Clip

Contact for Pricing

Overview

The Panduit LCA2/0-12-X is a tin-plated copper compression lug designed for reliable electrical connections. This one-hole, standard barrel lug is specified for 2/0 AWG stranded copper conductors and features a 3/8" (9.5 mm) stud hole size. The barrel is color-coded black and marked with Panduit die index number P45, along with competitor die index numbers, ensuring proper crimp die selection for consistent terminations. An integrated inspection window allows for visual verification of full conductor insertion, minimizing installation errors and ensuring a secure connection. Constructed from tin-plated copper, this lug offers excellent corrosion resistance, extending its service life in various industrial and utility applications. The LCA2/0-12-X is UL Listed and CSA Certified to 35 kV, and is temperature rated to 90°C. These ratings are valid when crimped with appropriate Panduit or specified competitor crimping tools and dies. The lug has a tongue width of 0.85" (21.6 mm) and a tongue thickness of 0.13" (3.3 mm). The barrel length is 0.98" (24.9 mm), and the overall length is 2.15" (54.6 mm). The wire strip length is 1-1/16" (26.9 mm). This product is manufactured in the USA. For optimal performance and safety, always consult the Panduit tool and die information and cable manufacturer's instructions for applications exceeding 2000V.
  • 2/0 AWG stranded copper conductor size
  • One-hole, standard barrel design with 3/8" (9.5 mm) stud hole
  • Tin-plated copper construction for corrosion resistance
  • Color-coded barrel (black) with Panduit P45 die index and competitor markings
  • UL Listed and CSA Certified to 35 kV, temperature rated to 90°C

Specifications

Angle*
Straight
Barrel Type*
Standard
Color
Black
Connection Type
Compression Lug
Material
Tin-Plated Copper
Material
Copper
Mounting
1-1/16 In.
Mounting Type
One-Hole Mounting
Mounting Type
One-Hole
Number Of Holes
1
Poles
1
Series
LCA2
Series
LCA
Size
Size 2/0
Size
2/0 AWG Code
Size
2/0 AWG
Special Features
Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Standard
UL Listed to 486A-486B File #E52164, NEBS Level 3, ABS
Stud Size
1/2 In.
Type
Compression Lug
Voltage Rating
35 kV
Package Dimensions (L x W x H)
5.85 IN x 3.35 IN x 3.3 IN
Package Weight (Imperial)
0.85 lbs
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.

AS-K1-H6

Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

How to Install Copper Compression Connectors

This guide provides step-by-step instructions for properly installing copper compression connectors, ensuring secure and reliable electrical connections.

Estimated time: 30m

Tools needed:

Wire strippers, Crimping tool, Multimeter

Supplies needed:

Copper compression connectors, Wire

  1. Select the appropriate connector

    Choose a connector that matches the wire size and material. Ensure you do not use a copper connector on aluminum wire.

  2. Prepare the wire

    Strip the wire insulation to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.

  3. Insert and crimp the connector

    Insert the stripped wire into the connector until it stops. Use the crimping tool to crimp the connector between the color bands or knurl markings, starting near the tongue end and moving towards the wire end.

  4. Inspect the crimp

    After crimping, check for any sharp edges, flash, or burrs on the connector and remove them if present.
