Overview
- Accommodates #10 AWG wire for reliable electrical connections
- 1/4" stud hole for secure mounting to terminals or bus bars
- Window lug design enables visual inspection of wire insertion
- Precision construction ensures tight, corrosion-resistant connections
- Made in USA, meets industry standards for electrical components
Specifications
Angle* | Straight |
Barrel Type* | Standard |
Connection Type | Barrel Lug |
Connection Type | Screw Terminal (Window Lug) |
Connection Type | Lug |
Connection Type | Screw Terminal |
Connection Type | Screw Terminal (stud) |
Material | Copper |
Material | Metal |
Material | Tin-plated Copper |
Mounting | 7/16 In. |
Mounting Type | One-hole barrel with window lug |
Mounting Type | One-hole barrel lug |
Mounting Type | One-hole, 1/4" stud |
Mounting Type | One-hole barrel with window |
Mounting Type | Screw |
Mounting Type | Stud |
Mounting Type | 1/4 stud hole |
Number Of Holes | 1 |
Series | LCA |
Series | LCA Series |
Size | #10 AWG |
Size | #10 AWG, 1/4" stud |
Size | #14 #10 AWG Code STR |
Size | #10 AWG, 1/4" stud hole |
Size | 1/4" stud hole |
Size | #14 — #10 AWG Code STR |
Special Features | Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
Standard | UL Listed to 486A-486B File #E52164, NEBS Level 3, ABS |
Stud Size | 1/4 In. |
Type | Compression Lug |
Package Dimensions (L x W x H) | 4.1 IN x 2.05 IN x 1.4 IN |
Package Weight (Imperial) | 0.415 lbs |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
2A-18
Non-Insulated Butt Splice, Length 0.63 Inches, Width 0.13 Inches, Wire Range 22-18 AWG, Copper, Tin Plated, 100 Pack
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install Copper Compression Connectors
This guide provides step-by-step instructions for properly installing copper compression connectors, ensuring secure and reliable electrical connections.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Multimeter
Supplies needed:
Copper compression connectors, Wire
- Select the appropriate connector
Choose a connector that matches the wire size and material. Ensure you do not use a copper connector on aluminum wire.
- Prepare the wire
Strip the wire insulation to the length specified in the tool chart. Avoid nicking or damaging the conductor strands.
- Insert and crimp the connector
Insert the stripped wire into the connector until it stops. Use the crimping tool to crimp the connector between the color bands or knurl markings, starting near the tongue end and moving towards the wire end.
- Inspect the crimp
After crimping, check for any sharp edges, flash, or burrs on the connector and remove them if present.
