Overview
- Accommodates #6 - #14 AWG Code or Flex conductors for both Run and Tap connections.
- Designed for making parallel and multiple tap connections.
- UL Listed and CSA Certified for applications up to 600V.
- Slotted design for quick and easy conductor assembly with cable ties.
- Manufactured in the USA for reliable quality.
Specifications
Application | Telecom/Data Center |
Color | Orange |
Connection Type | Compression |
Material | Copper |
Series | HTCT6X-6X-1 |
Size | #6 - #14 AWG |
Standard | cULus listed, CSA certified |
Type | Compression Tap |
Width | 0.4 In. |
Package Dimensions (L x W x H) | 4.65 IN x 3.95 IN x 0.6 IN |
Package Weight (Imperial) | 0.006 lbs |
PUP6C04OR-ULP
The TX6 Cat 6 U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs. All four pairs shall be covered by a flame retardant PVC (CMP), Orange jacket. Packaged 1000 ft./305m in an easy payout carton.
HTCT2-2-1
Copper Compression HTAP with code #2 - #6 AWG STR/SOL Run and Tap 1, code #8 - #14 AWG Tap 2 and Tap 3 or flex #2 - #8 AWG Run and Tap 1 and flex #8 - #14 AWG Tap 2 and Tap 3.
LCD4-12-L
Copper Compression Lug, 2 Hole, #4 AWG Code Conductor, Standard Barrel, 1/2" Stud, 1.75" Hole Spacing
LCB4/0-12WF-X
Copper Compression Lug, 1 Hole, 4/0 AWG, Long Barrel, 1/2"(12,7mm) Stud, Window, 90 Bent
PSL-DCPLE-OR
The Lock-In device secures patch cord connections to prevent unauthorized access or accidental removal. Standard device is used when jacks mount flush with the surface. Extended hood protects locking mechanism. Includes 10 orange devices and one removal tool.
PSL-DCPLE-OR-C
The Lock-In device secures patch cord connections to prevent unauthorized access or accidental removal. Standard device is used when jacks mount flush with the surface. Extended hood protects locking mechanism. Includes 100 orange devices and five removal tools.
PSL-DCPLRE-OR
The Lock-In device secures patch cord connections to prevent unauthorized access or accidental removal. Recessed device is used when jacks mount slightly deeper from the surface. Extended hood protects locking mechanism. Includes 10 orange devices and one removal tool.How to Install the HTCT2-2-1 Controller
This guide provides step-by-step instructions for installing and configuring the HTCT2-2-1 controller, ensuring proper wiring and calibration.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the HTCT2-2-1 controller to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the wiring
Strip the ends of the wires to the appropriate length as specified in the documentation. Connect the wires to the terminal connectors, ensuring a secure fit.
- Verify connections
Use a multimeter to check the continuity of the connections. Ensure there are no shorts and that all connections are secure before powering on the device.
- Power on the controller
Turn on the power supply to the HTCT2-2-1 controller. Observe the indicator lights to confirm that the device is functioning correctly.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure the controller is set to the correct parameters for your application.
