Panduit HSTT12-CC - The HSTT12-CC Thin Wall Heat Shrink Tubing shrinks around wires, connectors, joints, and terminals when heated to protect against abrasion. Applications include insulating and protecting wires/cables in indoor, dry locations. Shrink ratio: 2:1. Temperature range: -67 F to 275 F (-55 C to 135 C). Cross-linked polyolefin. 0.125 Diameter x 100 Long (3.2 mm x 30.5 m). Color Clear. 1 roll.
Panduit

HSTT12-CC

UPC: 074983747177

Documents & Media
Technical DrawingFull Engineering DrawingInstallation InstructionsVideo Clip

Contact for Pricing

Overview

The Panduit HSTT12-CC is a high-quality, thin-wall heat shrink tubing designed for essential wire and cable management in indoor, dry environments. Manufactured from cross-linked polyolefin, this tubing offers robust protection against abrasion for wires, connectors, joints, and terminals. Upon application of heat, the HSTT12-CC shrinks to form a tight, protective barrier, ensuring the integrity and longevity of electrical connections. Key specifications include a 2:1 shrink ratio, meaning the tubing will reduce to half its original diameter when heated, providing a secure fit around various component sizes. Its operational temperature range spans from -67°F to 275°F (-55°C to 135°C), making it suitable for a broad spectrum of applications where moderate temperature fluctuations are expected. The material's cross-linked polyolefin composition offers excellent dielectric strength and mechanical resilience. This specific SKU, HSTT12-CC, comes in a clear color, allowing for visual inspection of the underlying connection. The dimensions are 0.125 inches (3.2mm) in diameter and it is supplied in a convenient 100-foot (30.5m) roll, providing ample material for numerous projects. The HSTT series from Panduit is recognized for its reliability and ease of use, making it a go-to choice for electricians, technicians, and maintenance professionals. Applications include insulation and protection in control panels, telecommunications equipment, and general electrical wiring. Panduit's commitment to quality is evident in the durable construction of the HSTT12-CC, ensuring dependable performance. The clear color facilitates easy identification of connections after installation. The 2:1 shrink ratio simplifies selection, as it accommodates a wide range of wire and connector diameters. Trust the Panduit HSTT12-CC for effective and reliable wire protection.
  • Protects wires, connectors, joints, and terminals from abrasion when heated.
  • Ideal for insulating and protecting wires/cables in indoor, dry locations.
  • 2:1 shrink ratio for a secure fit.
  • Wide temperature range: -67°F to 275°F (-55°C to 135°C).
  • Clear color for visual inspection; made from durable cross-linked polyolefin.

Specifications

Application
For Dry Locations;Insulating and protecting wires and cables
Color
Colorless
Color
Colourless
Flammability
N/A
Inside Diameter After Heat-Shrink
0.062 in
Inside Diameter After Heat-Shrink
1.5748 mm
Inside Diameter Before Heat-Shrink
0.062 in
Inside Diameter Before Heat-Shrink
1.5748 mm
Minimum Shrink Temperature
194 F
Minimum Shrink Temperature
90 C
Operating Temperature, Maximum
275 F
Operating Temperature, Maximum
135 C
Operating Temperature, Minimum
275 F
Operating Temperature, Minimum
135 C
Outside Diameter
0.12 in
Outside Diameter
3.048 mm
Shrink Ratio
2:1
Standard
Mil Spec: AMS-DTL-23053/5 Class 2
Thickness
0.02 in
Thickness
0.508 mm
Type
Heat-Shrink
Package Dimensions (L x W x H)
6.7 IN x 5.75 IN x 2.9 IN
Package Weight (Imperial)
0.99 lbs
Thin wall heat shrink, .12" (3.2mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.

HSTT12-48-QC

Thin wall heat shrink, .12" (3.2mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.
Thin wall heat shrink, .09" (2.4mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5m) per reel.

HSTT09-CC

Thin wall heat shrink, .09" (2.4mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5m) per reel.
Thin wall heat shrink, .09" (2.4mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.

HSTT09-48-QC

Thin wall heat shrink, .09" (2.4mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.
The HSTT06-CC Thin Wall Heat Shrink Tubing shrinks around wires, connectors, joints, and terminals when heated to protect against abrasion. Applications include insulating and protecting wires/cables in indoor, dry locations. Shrink ratio: 2:1. Temperature range: -67 F to 275 F (-55 C to 135 C). Cross-linked Polyolefin. 0.063 Diameter x 100 Long (1.6 mm x 30.5 m). Color Clear. 1 roll.

HSTT06-CC

The HSTT06-CC Thin Wall Heat Shrink Tubing shrinks around wires, connectors, joints, and terminals when heated to protect against abrasion. Applications include insulating and protecting wires/cables in indoor, dry locations. Shrink ratio: 2:1. Temperature range: -67 F to 275 F (-55 C to 135 C). Cross-linked Polyolefin. 0.063 Diameter x 100 Long (1.6 mm x 30.5 m). Color Clear. 1 roll.
Thin wall heat shrink, .06" (1.6mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.

HSTT06-48-QC

Thin wall heat shrink, .06" (1.6mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.
Thin wall heat shrink, .19" (4.8mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5m) per reel.

HSTT19-CC

Thin wall heat shrink, .19" (4.8mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5m) per reel.
Thin wall heat shrink, .19" (4.8mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.

HSTT19-48-QC

Thin wall heat shrink, .19" (4.8mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.
Thin wall heat shrink, .05" (1.2mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5) per reel.

HSTT05-CC

Thin wall heat shrink, .05" (1.2mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5) per reel.
Thin wall heat shrink, .05" (1.2mm) diameter, clear cross-linked polyolefin, 250 pc. package quantity.

HSTT05-48-TLC

Thin wall heat shrink, .05" (1.2mm) diameter, clear cross-linked polyolefin, 250 pc. package quantity.
Thin wall heat shrink, .05" (1.2mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.

HSTT05-48-QC

Thin wall heat shrink, .05" (1.2mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity.
The HSTT25-48-QC Thin Wall Heat Shrink Tubing shrinks around wires, connectors, joints, and terminals when heated to protect against abrasion. Applications include insulating and protecting wires/cables in indoor, dry locations. Shrink ratio: 2:1. Temperature range: -67 F to 275 F (-55 C to 135 C). Cross-linked polyolefin. 0.25 Diameter x 4 Long (6.4 mm x 1.2 m). Color Clear. 25 per package.

HSTT25-48-QC

The HSTT25-48-QC Thin Wall Heat Shrink Tubing shrinks around wires, connectors, joints, and terminals when heated to protect against abrasion. Applications include insulating and protecting wires/cables in indoor, dry locations. Shrink ratio: 2:1. Temperature range: -67 F to 275 F (-55 C to 135 C). Cross-linked polyolefin. 0.25 Diameter x 4 Long (6.4 mm x 1.2 m). Color Clear. 25 per package.
Thin wall heat shrink, .25" (6.4mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5m) per reel.

HSTT25-CC

Thin wall heat shrink, .25" (6.4mm) diameter, clear cross-linked polyolefin, 100 ft. (30.5m) per reel.

How to Install Heat Shrink Tubing

This guide provides step-by-step instructions for properly installing heat shrink tubing to ensure effective insulation and protection of electrical connections.

Estimated time: 15m

Tools needed:

Heat gun, Infrared heat source, Soft yellow flame torch, Oven

Supplies needed:

Heat shrink tubing

  1. Position the heat shrink tubing

    Place the heat shrink tubing over the object to be covered without stretching it.

  2. Heat the tubing

    Using a heat gun, infrared heat source, soft yellow flame torch, or oven, evenly heat the tubing until it fully recovers and conforms to the object.

  3. Avoid charring

    Ensure that you do not char or burn the tubing during the heating process.
