Contact for Pricing
Minimum Qty: 10
Multiplier: 1
*Contact for lower quantities*
Overview
- Splits one optical signal into sixteen outputs
- Utilizes Planar Lightwave Circuit (PLC) technology
- Features one SC-APC input and sixteen SC-APC outputs
- Small form factor designed for FPONE enclosures
- Passive device, no external power required
Specifications
Application | Passive Optical LAN |
Color | Acid Green |
Depth | NA In. |
Material | Polycarbonate |
Standard | GR-1209-CORE, GR-1221-CORE |
Type | Fiber Optic Splitter |
Width | NA In. |
Package Dimensions (L x W x H) | 7.8 IN x 4.5 IN x 1.5 IN |
Package Weight (Imperial) | 0.74 lbs |
FPONCS1X32
The in-line, connectorized fiber optic splitter is a small form factor passive device that fits in FPONE enclosures and uses a planar lightwave circuit to split one signal to sixteen signals for passive optical network applications. The splitter includes one SC-APC input on one side and thirty-two SC-APC outputs on the opposite side.
PSL-DCPLRE-GR-C
The Lock-In device secures patch cord connections to prevent unauthorized access or accidental removal. Recessed device is used when jacks mount slightly deeper from the surface. Extended hood protects locking mechanism. Includes 100 green devices and five removal tools.
PSL-DCPLE-GR
The Lock-In device secures patch cord connections to prevent unauthorized access or accidental removal. Standard device is used when jacks mount flush with the surface. Extended hood protects locking mechanism. Includes 10 green devices and one removal tool.
PSL-DCPLRE-GR
The Lock-In device secures patch cord connections to prevent unauthorized access or accidental removal. Recessed device is used when jacks mount slightly deeper from the surface. Extended hood protects locking mechanism. Includes 10 green devices and one removal tool.
Frequently Asked Questions
What form factor do these PLC splitters have?
The PLC splitters are in a discrete form factor for use in wall-mounted PON enclosures.
What splitter configurations are available?
PLC splitters are available in 1X4, 1X8, 1X16, and 1X32 configurations.
What connector options are available for the splitters?
Splitters can be bare-fiber or pre-connectorized with SC-APC pre-polished connectors.
What is the primary application of these splitters?
These splitters are used in passive optical networks to divide a single fiber signal into multiple channels for optical network terminal installation.
What is the operating wavelength range?
The operating wavelength range for these splitters is 1260-1650nm.
What is the insertion loss for a 1X16 splitter?
The insertion loss for a 1X16 splitter is 14.2dB. Note that these values do not include connector loss.
What is the IL uniformity for a 1X16 splitter?
The IL uniformity for a 1X16 splitter is 1.5dB.
What is the polarization dependency for a 1X16 splitter?
The polarization dependency for a 1X16 splitter is 0.4dB.
What is the directivity of the splitters?
The directivity of the PLC splitters is greater than 55dB.
What is the return loss of the splitters?
The return loss of the PLC splitters is greater than 55dB.
How to Install the FPONCS1X16 Fiber Optic Splitter
This guide provides step-by-step instructions for installing and configuring the FPONCS1X16 Fiber Optic Splitter.
Estimated time: 45m
Tools needed:
Screwdriver, Cable tie tool, Fusion splice equipment
Supplies needed:
Mounting screws, Splice covers, Labeling materials
- Mount the splitter housing
Secure the metallic housing of the FPONCS1X16 splitter in the splice tray above the splice holding slots using a cable tie.
- Route the input fiber
Route the input fiber to the fiber storage spool area, ensuring it is properly organized and secured.
- Perform fusion splicing
Using the fusion splice equipment, splice the input side of the splitter, then repeat the process for the output side fibers. Cover each splice with a splice cover and mount them in storage trays.
- Document and label fiber routing
Document the fiber routing and label each section clearly for future reference.
