CJLR688TGIG

The 45° angled wire caps provide improved cable routing to jacks in confined spaces.

They are used in confined spaces like modular furniture, raceway, and wall outlets. They are beneficial for Category 6A cabling and in high-density rack cabling.

Yes, both wire cap versions can be inserted into compatible jacks in either direction. This design allows two parts to handle up, down, left, or right cable routing.

The recommended termination tool is TGSJT. Wire snipping tools CWST and CJAST are also listed.

The operating temperature range for these wire caps is 14°F to 167°F (-10°C to 75°C).

They allow up to a 55% reduction in cable routing depth compared to straight exit wire caps. This means 0.5 in. depth with angled caps versus 1.1 in. with straight exit caps for 0.275 in. diameter cable.

They are compatible with 22-26 AWG solid or stranded cable. Conductor insulation diameter must be 0.060 in. max, and overall cable O.D. 0.2 in. - 0.33 in.

Yes, they are UL 2043 compliant, making them suitable for use in air-handling spaces. They also comply with UL 1863 as a communications circuit accessory.

Yes, they meet IEEE 802.3af/at and 802.3bt type 3 and 4 standards. They also support Power over HDBaseT up to 100 watts.

When mated with compatible jack modules, these wire caps exceed ANSI/TIA-568.2-D and ISO 11801 channel and component requirements.
