NSI Industries
76070PS
UPC: 662381760708
Contact for Pricing
Overview
- SPST N.O. circuit function
- 15A/125VAC and 10A/250VAC ratings
- Brass/nickel construction
- Nickel screw terminals
- Momentary action with pushbutton actuator
Specifications
Actuator | NSI |
Amperage Rating | 10;15 A;A |
Application | Motor-Equipment Control |
Color | Nickel |
Connection Type | Nickel Screw Terminals |
Connection Type | Screw Connection |
Contact Configuration | SPST NO |
Contact Rating | 15 Amp (125 VAC) - 10 Amp (250 VAC) |
Current Rating | 15A@125VAC/10A@250VAC |
Height | 0.562 in |
Height | 14.2748 mm |
Material | Brass/Nickel |
Material | Nickel |
Method of Operation | Push Button |
Method of Operation | Push Button;Push button |
Model | Push Button |
Mounting | Screw Mount |
Mounting Type | Panel Mount |
Number of poles | 1.0000 |
Poles | 1P |
Poles | SPST N.O. |
Size | 0.576" x 0.562" x 1.382" |
Special Features | SPST NO - Off-Momentary On - Screw Type Connectors |
Voltage Rating | 125VAC/250VAC |
Voltage Rating | 125-250 VAC |
Warranty | 1 Year |
Width | 0.576 in |
Width | 14.6304 mm |
Package Dimensions (L x W x H) | 1.382 IN x 1.382 IN x 1.138 IN |
Package Dimensions (L x W x H) | 3.5103 cm x 3.5103 cm x 2.8905 cm |
Package Weight (Imperial) | 0.066 L |
Package Weight (Metric) | 0.030 kg |
