NSI Industries
76050PS
UPC: 662381760500
Contact for Pricing
Overview
- SPST maintained-action pushbutton switch for reliable electrical control
- Rated 6A at 125VAC and 3A at 250VAC for versatile AC/DC applications
- Screw terminals ensure secure wire connections in industrial environments
- Durable brass/nickel actuator with compact dimensions (0.437" x 0.542" x 1.183")
- Panel-mount design suitable for control panels, machinery, and instrumentation
Specifications
Actuator | NSI |
Amperage Rating | 3;6 A;A |
Application | Motor-Equipment Control |
Connection Type | Screw Terminal |
Contact Configuration | SPST |
Contact Rating | 6 Amp (125 VAC) - 3 Amp (250 VAC) |
Current Rating | 6A/3A |
Current Rating | 6 A |
Height | 0.562 in |
Height | 14.2748 mm |
Material | Brass/Nickel |
Method of Operation | Push Button;Push button |
Method of Operation | Push Button |
Model | Push Button |
Mounting | Screw Mount |
Mounting Type | Panel Mount |
Number of poles | 1.0000 |
Poles | 1P |
Poles | SPST |
Size | 0.437 in x 0.542 in x 1.183 in |
Size | A: 0.437 in, C: 0.542 in, D: 1.183 in |
Special Features | SPST - Push On-Push Off - Screw Type Connectors |
Voltage Rating | 125 VAC |
Voltage Rating | 125-250 VAC |
Voltage Rating | 125VAC/250VAC |
Warranty | 1 Year |
Width | 0.542 in |
Width | 13.7668 mm |
Package Dimensions (L x W x H) | 1.183 IN x 0.562 IN x 0.542 IN |
Package Dimensions (L x W x H) | 3.0048 cm x 14.2748 mm x 13.7668 mm |
Package Weight (Imperial) | 0.056 L |
Package Weight (Metric) | 0.025 kg |
