Overview
- 3-1/2 inch malleable iron construction for durability and corrosion resistance
- Type T design with 90-degree angle and single hub entry for right-angle conduit runs
- Internal volume capacity of 91 cubic inches (1489.5 cubic cm) for ample conductor space
- Compatible with rigid metal conduit (RMC) and intermediate metal conduit (IMC) systems
- Double-grip saddle design for simplified installation and salvageable design for future modifications
Specifications
Application | Allows access to the interior of a conduit system for inspection, pulling and maintenance. |
Conduit Body Form/Series | Form 35/Series 5 |
Conduit Body Type | T |
Finish | Zinc Electroplated |
Hub Size | 3.5 |
Material Quality | Malleable Iron |
Standard | UL |
Trade Size | 3-1/2 in |
Type | Type T |
Package Dimensions (L x W x H) | 17.875 IN x 9.625 IN x 6 IN |
Package Dimensions (L x W x H) | 45.4025 cm x 24.4475 cm x 15.24 cm |
Package Weight (Imperial) | 22.450 L |
Package Weight (Metric) | 10.183 kg |
Frequently Asked Questions
What is the application of the T-69?
The T-69 allows access to the interior of a conduit system for inspection, pulling, and maintenance.
What certifications does the T-69 have?
The T-69 meets Federal Specification W-C-586D, NEMA Standard FB-1, and UL Standard UL-514A.
What material is the T-69 made from?
The T-69 is made from malleable iron.
What is the finish of the T-69?
The T-69 has a zinc electro-plate finish.
What is the standard package quantity for the T-69?
The standard package quantity for the T-69 is 1.
What are the dimensions of the T-69?
The dimensions are 18.50 x 5.50 x 5.38 x 15.00 inches.
What is the trade size of the T-69?
The trade size of the T-69 is 3-1/2 inches.
