NSI Industries L10N - 2 Hole Long Barrel Copper Compression Lug 1/0 AWG - 1/2" Bolt Long Barrel Copper Compression Lugs are produced from high conductivity copper tubing. Allows easy inspection of the termination to assure complete cable insertion. Tin-plated to provide corrosion and low contact resistance. Marked with die index and color coded. Listed for 35KV maximum when properly installed. Rated 600V. cULus 486A/B Listed. UL467 Listed on sizes 6 AWG - 3/0 AWG. Temperature rating 90 degrees C.
NSI Industries

L10N

UPC: 662381035097

Documents & Media
Technical Bulletin

Contact for Pricing

Overview

The NSI Industries L10N is a high-conductivity copper compression lug designed for reliable electrical connections. Manufactured from premium copper tubing, this long barrel lug ensures complete cable insertion, which can be easily inspected through its design. The tin-plated finish provides excellent corrosion resistance and maintains low contact resistance for optimal electrical performance. Each lug is clearly marked with its die index and color-coded for quick identification, streamlining installation and inventory management. Rated for 600V and suitable for 35KV maximum applications when properly installed according to cable manufacturer instructions, the L10N is cULus 486A/B Listed and UL467 Listed for grounding and bonding on sizes 6 AWG through 3/0 AWG. Its temperature rating is 90°C. This specific model, SKU L10N, features a 1/0 AWG wire range and a 1/2" bolt size, with a barrel inner diameter of 0.390" and outer diameter of 0.520". The mounting hole spacing (D) is 1.000", and the overall length (L) is 3.210". The width (W) is 0.740", with an end-of-connector-to-center measurement (A) of 0.380". Tang length (B) is 1.810", barrel length (B1) is 1.200", and tang thickness (C) is 0.130". The mounting hole diameter (E) is 0.250". This lug is manufactured in the USA and is ideal for various industrial and utility applications requiring robust and durable electrical terminations.
  • Constructed from high-conductivity copper tubing for superior conductivity.
  • Tin-plated for enhanced corrosion resistance and low contact resistance.
  • Long barrel design allows for easy visual inspection of cable insertion.
  • Marked with die index and color-coded for efficient identification.
  • Rated 600V, 35KV max (when properly installed), cULus 486A/B Listed, UL467 Listed.

Specifications

Application
Terminate, Splice, Tap Power Connectors
Cable Size
1/0 AWG (STR)
Color
Pink
Connection Type
Compression Lug
Environmental Conditions
90 C
Finish
Tin Plated
Material
Copper
Mounting
1/2 Mounting Holes
Number Of Holes
2
Size
L=4.63 - W=.740 - OD=.520 - ID=.390
Size
1/0 AWG
Special Features
1/0 AWG (STR) - 1/2 Mounting Holes - 1 3/4 Hole Spacing
Standard
UL486A/B, UL467 (8 AWG -3/0 AWG)
Stud Size
1/2 IN
Type
Long Barrel - Two Hole
Voltage Rating
600 V
Warranty
1 Year
Package Dimensions (L x W x H)
4.63 IN x 0.74 IN x 0.52 IN
Package Dimensions (L x W x H)
11.7602 cm x 18.796 mm x 13.208 mm
Package Weight (Imperial)
6.000 L
Package Weight (Metric)
2.722 kg
