Contact for Pricing
Overview
- Constructed from high conductivity aluminum tubing for optimal electrical performance.
- Electro-tin plated finish provides excellent corrosion resistance and low contact resistance.
- Features a center stop to ensure correct cable insertion and secure termination.
- Color-coded and marked with die index for easy identification and proper tool selection.
- UL Listed for 35KV maximum when installed according to cable manufacturer specifications.
Specifications
Application | Terminate, Splice, Tap Power Connectors |
Cable Size | 300 MCM (STR) |
Color | Blue |
Connection Type | Compression Lug |
Environmental Conditions | 90 C |
Finish | Tin Plated Bronze |
Material | Aluminum |
Mounting | 1/2 Mounting Hole |
Number Of Holes | 1 |
Size | L=4.00 - W=1.37 - OD=1.01 - ID=.649 |
Size | 300 MCM |
Special Features | 300 MCM (STR) - 1/2 Mounting Hole |
Standard | UL486A/B |
Stud Size | 1/2 IN |
Type | Standard Barrel - One Hole |
Voltage Rating | 600 V |
Voltage Rating | 35 kV |
Warranty | 1 Year |
Package Dimensions (L x W x H) | 4 IN x 1.37 IN x 1.012 IN |
Package Dimensions (L x W x H) | 10.16 cm x 3.4798 cm x 2.5705 cm |
Package Weight (Imperial) | 1.200 L |
Package Weight (Metric) | 0.544 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
How to Install the AL300-48 Aluminum Connectors
This guide provides step-by-step instructions for installing and wiring AL300-48 aluminum connectors for optimal performance.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Multimeter
Supplies needed:
Aluminum connectors, Wire brush, Mounting screws
- Prepare the conductor
Carefully strip the insulation from the conductor to the appropriate length, ensuring that the strands are not nicked.
- Clean the conductor
Use a wire brush to clean the stripped portion of the conductor, removing any oxide films to ensure a good connection.
- Insert the conductor
Insert the cleaned and stripped conductor completely into the barrel of the aluminum connector, ensuring it fills the barrel.
- Crimp the connector
Using the appropriate crimping tool, crimp the connector according to the manufacturer's specifications for the wire size.
- Verify the connection
Use a multimeter to check the continuity and ensure that the connection is secure and functioning correctly.
