NSI Industries AL-P2-P2 - Power Distribution Block (2) 350 MCM-6 AWG Primary (2) 350 MCM-6 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
NSI Industries

AL-P2-P2

UPC: 662381166197

Documents & Media
Technical Bulletin

Contact for Pricing

Overview

The NSI Industries AL-P2-P2 Power Distribution Block is an aluminum alloy block engineered for primary and secondary power distribution in industrial environments. Rated for 350 MCM to 6 AWG wire sizes, this block supports two primary and two secondary connections, making it suitable for panel boards, motor control centers, and distribution panels. Constructed with a high-strength glass-filled polyester base, the AL-P2-P2 delivers durability and resistance to environmental stresses while maintaining electrical integrity. The modular design allows standalone use or integration into multi-block configurations for expanded distribution needs. Each block is made of high-strength, high-conductivity aluminum alloy, ensuring efficient power transfer with minimal resistance. The high-strength glass-filled polyester base provides structural integrity and protection against corrosion, chemicals, and temperature extremes. The AL-P2-P2 is designed to meet the demands of commercial, industrial, and utility applications where reliable power distribution is critical. NSI Industries, a trusted U.S.-based manufacturer, delivers this block with a focus on performance and longevity, ensuring long-term reliability in harsh operating conditions. The block's design supports compliance with industry standards for electrical safety and performance.
  • Aluminum alloy construction for high strength and conductivity
  • Supports 350 MCM to 6 AWG wire sizes
  • Two primary and two secondary connections
  • High-strength glass-filled polyester base for durability
  • Modular design for standalone or multi-block configurations

Specifications

Amperage Rating
620 Amps Per Pole
Application
NSI
Color
Black
Connection Type
Screw Terminal (implied)
Material
Aluminum body -Glass Filled Polyester Base
Material
Aluminum alloy, glass-filled polyester
Mounting
2 Mounting Holes
Mounting Type
Modular (standalone or multi-block)
Number Of Terminals
4
Poles
2 primary, 2 secondary
Size
350 MCM to 6 AWG
Size
L=5.50 - H=3.25 - W=2.90 IN
Special Features
(2) 350 MCM-6 AWG (Line Side) - (2) 350 MCM-6 AWG (Load Side) - 620 Amps Per Pole
Standard
Recognized to UL1059
Type
Splicer/Reducer
Voltage Rating
600 V
Warranty
1 Year
Wire Size
(2) 350 MCM-6 AWG(LINE) - (2) 350 MCM-6 AWG(LOAD)
Package Dimensions (L x W x H)
5.5 IN x 2.9 IN x 3.25 IN
Package Dimensions (L x W x H)
13.97 cm x 7.366 cm x 8.255 cm
Package Weight (Imperial)
3.672 L
Package Weight (Metric)
1.666 kg
