Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- UL-listed (File No. E 1383) and CSA-certified (File No. 2884) for compliance with electrical codes
- One-piece formed steel body with rounded bushing to protect cables during installation
- TITE-BITE® connector secures flexible metal cable with a single screw for quick, tool-free installation
- Armor gripping saddle stays open for easy cable insertion and alignment
- Malleable iron construction ensures durability in industrial and commercial environments
- Cable opening range: 0.250" to 0.656" for compatibility with standard Duplex AC/MC cables
- Meets NEC 350-5 requirements for grounding applications
Specifications
Application | The 4156-DC is used to securely join 1/2" EMT to two 14/2 to 10/3 (.43" to .61" Diameter) AC/MC/MCI-A/HCF/HCFMCI-A or 3/8" flexible metal conduit. These fittings provide a huge labor savings, compared to the traditional junction box or fitting assembly installation. When using AC/MC/FMC cable simply remove the armor and expose the conductors to the desired length needed to reach the device box or enclosure. The inspection holes will provide a visual end stop for the cable or flex conduit. The use of anti short bushings is recommended. Tighten the steel screws for the 1/2" EMT conduit. Patented. |
Connection Type | Coupling |
Material | Metal |
Material Quality | Zinc Die Cast |
Series | Mighty-Merge |
Size | 1/2" EMT to Duplex AC/MC |
Special Features | Set Screw type transition fitting ideal for commercial and institutional facilities. |
Standard | cETLus |
Trade Size | 0.5 in |
Type | Coupling |
Package Weight (Imperial) | 0.273 L |
Package Weight (Metric) | 0.124 kg |
Frequently Asked Questions
What is the purpose of the 4156-DC fitting?
The 4156-DC is a set screw type transition fitting used to securely join 1/2" EMT to two 14/2 to 10/3 AC/MC/MCI-A/HCF/HCFMCI-A or 3/8" flexible metal conduit.
What types of conduit does the 4156-DC fit with?
It fits with 1/2" EMT and two 14/2 to 10/3 AC/MC/MCI-A/HCF/HCFMCI-A or 3/8" flexible metal conduit.
What materials are used in the 4156-DC fitting?
The 4156-DC fitting is made of zinc die cast material.
What is the recommended installation practice?
When using AC/MC/FMC cable, remove the armor and expose the conductors to the desired length, using the inspection holes as a visual end stop.
What certifications does the 4156-DC have?
The 4156-DC is CSA certified and UL cETLus listed.
What are the dimensions of the 4156-DC fitting?
The dimensions are: A = 2.99 inches, B = 1.30 inches, C = 1.98 inches.
Are anti-short bushings necessary?
Yes, the use of anti-short bushings is recommended during installation.
What is the patent status of the 4156-DC?
The 4156-DC has several patents, including D581,877 and 7,402,752.
What is the standard package quantity for the 4156-DC?
The standard package quantity for the 4156-DC is 40 units.
What is the UPC number for the 4156-DC?
The UPC number for the 4156-DC is 78174794156.
