Contact for Pricing
Overview
- 4-inch EMT slip coupling with hardened steel set screw for secure conduit connections
- Eliminates conduit threading with positive holding strength and grounding
- Insulated nylon throat reduces wire pulling effort by up to 50%
- Concrete-tight design approved for harsh environments
- UL 514B and CSA C22.2 No. 18 certified
Specifications
Application | Mighty-Align™ "Slip" Style Coupling - Used to join two ends of 4" EMT together. Backing out center screw allows 249-DCSLP to be temporarily located on one cut end while adjacent end is slid into place. -Back out center screw stop as necessary to slip coupling over conduit. -Fully install center screw stop between conduits. -Ensure that both ends of conduit are visible in sight hole. -Tighten all set screws. Patented |
Connection Type | Set Screw |
Length | 133.3500;5.250000000000000 in;in |
Length | 5.25 in |
Length | 133.35 mm |
Material | Malleable Iron with Electro Zinc Plated and Chromate Coated Finish |
Material Quality | Zinc Die Cast |
Outside Diameter | 5.02 in |
Outside Diameter | 127.508 mm |
Size | 4" EMT |
Special Features | Use in tight or limited access applications |
Standard | cULus, E24001 |
Trade Size | 4 in. |
Type | Slip |
Package Weight (Imperial) | 1.650 L |
Package Weight (Metric) | 0.748 kg |
Frequently Asked Questions
What is the application of the 249-DCSLP?
The 249-DCSLP is a Mighty-Align™ 'Slip' Style Coupling used to join two ends of 4" EMT together.
What are the dimensions of the 249-DCSLP?
The dimensions are 5.25 inches for Dimension A and 5.02 inches for Dimension B.
What is the trade size of the 249-DCSLP?
The trade size of the 249-DCSLP is 4 inches.
What material is the 249-DCSLP made from?
The 249-DCSLP is made from zinc die cast.
How is the 249-DCSLP installed?
To install, back out the center screw to temporarily locate the coupling, then slide the adjacent end into place and tighten all set screws.
Where is the 249-DCSLP manufactured?
The 249-DCSLP is manufactured in the USA.
What is the finish of the 249-DCSLP?
The finish of the 249-DCSLP is ball burnished mirror smooth.
What certifications does the 249-DCSLP have?
The 249-DCSLP is certified under NEMA Standard FB-1 and UL Standard UL514B.
What is the patent status of the 249-DCSLP?
The 249-DCSLP is patent pending with patent number D702,542.
How many units are in a standard package?
The standard package quantity for the 249-DCSLP is 6 units.
