Mersen TS63-3 - Terminal shrouds are used to prevent the contact of live terminals. They are made for all of our switches, both line and load sides. 63A 3 poles NFDS series.
Mersen

TS63-3

Alternate Item Number: 3605340559255

Contact for Pricing

Overview

Enhance the safety and reliability of your electrical installations with the Mersen TS63-3 Terminal Shrouds. Engineered by Mersen, a global leader in electrical protection and power management, these terminal shrouds are specifically designed to provide superior insulation for live terminals on 63A, 3-pole NFDS series switches. Preventing accidental contact is paramount in industrial environments, and the TS63-3 series offers a robust solution to mitigate electrical hazards and ensure operational continuity. These essential safety accessories are crucial for compliance with stringent electrical safety standards. By effectively covering both the line and load sides of your NFDS switches, the TS63-3 shrouds create a physical barrier that significantly reduces the risk of short circuits, arc flashes, and personal injury. This proactive approach to safety is vital in sectors such as manufacturing, utilities, data centers, and building management systems where uninterrupted and safe power distribution is non-negotiable. The Mersen TS63-3 Terminal Shrouds are constructed from high-quality, durable materials that are resistant to environmental factors commonly found in industrial settings. Their design ensures a secure fit and straightforward installation, minimizing downtime during maintenance or upgrades. Professionals can trust in Mersen's commitment to quality and innovation, knowing that these shrouds are built to withstand demanding operational conditions and provide long-lasting protection. Key benefits and features of the Mersen TS63-3 Terminal Shrouds include: Enhanced Safety: Prevents direct contact with live terminals, significantly reducing the risk of electrical shock and arc flash incidents. Broad Compatibility: Specifically designed for Mersen's 63A, 3-pole NFDS series switches, ensuring a perfect fit and optimal performance. Comprehensive Protection: Covers both line and load sides of the switch, offering complete terminal insulation. Durable Construction: Made from robust, industrial-grade materials for longevity and resistance to harsh environments.
  • Designed for Mersen 63A, 3-pole NFDS series switches
  • Prevents direct contact with live terminals
  • Covers both line and load sides for complete insulation
  • Durable, industrial-grade construction
  • Facilitates compliance with electrical safety standards

Specifications

Application
for use with Mersen switches
Brand Name
Ferraz Shawmut
Current Rating
63 A
Material
Industrial-grade materials
Poles
3 poles
Series
NFDS series
Special Features
Terminal shrouds are used to prevent the contact of live terminals. They are made for all of our switches, both line and load sides.
Standard
UL98 recognized to E191605
Type
Accessories for Switches
Voltage Rating
600 VAC
Package Dimensions (L x W x H)
3.937 IN x 3.937 IN x 4.7244 IN
Package Dimensions (L x W x H)
10 cm x 10 cm x 12 cm
Package Weight (Imperial)
0.063 L
Package Weight (Metric)
0.029 kg
