Contact for Pricing
Minimum Qty: 5
Multiplier: 5
*Contact for lower quantities*
Overview
- Fast-acting for rapid fault clearance
- Glass body for visual inspection of the fusible element
- Ferrule terminals for secure connection
- UL Recognized for low-voltage AC applications
- Suitable for control panels, power supplies, instrumentation, and telecommunications systems
Specifications
AC Voltage Rating | 32 V |
Amperage Rating | 20 A |
Application | Electronic circuits |
Brand Name | Mersen |
Case | Glass |
Case Material | Glass |
Class | Supplemental |
Connection | Ferrule |
Mounting | Clip |
Size | 1.25 x 0.25 in |
Size | 31.75 x 6.35 mm |
Size | 1.25 x 0.25;31.75 x 6.35 in;mm |
Special Features | Glass body Fast-acting 1/4" x 1-1/4" |
Standard | 1/10A through 10A, 250VAC, UL Listed and CSA Certified 12A and 15A, 125VAC, UL Listed and CSA Certified 20A through 30A, 32VAC |
Type | 6x32mm, 1/4" X 1-1/4" |
Voltage Rating | 32 VAC |
Package Dimensions (L x W x H) | 1.25 in x 0.25 in x 0.25 in |
Package Dimensions (L x W x H) | 31.75 mm x 6.35 mm x 6.35 mm |
Package Weight (Imperial) | 0.010 lb |
Package Weight (Metric) | 0.005 kg |
