Mersen AJT1-6/10 - Amp-Trap 2000 time-delay AJT fuses provide IEC Type "2" (No Damage) protection to main, feeder, and branch-circuits, for all types of loads - yet, they require only half the mounting space needed for 600V UL Class RK fuses. Time-delay characteristics handle motor in-rush currents without nuisance trips. Its current-limiting ability and wide range of ratings provide excellent overcurrent protection for all your applications. An optional mechanical blown fuse indicator and Microswitch is available on blade-type (70 to 600A) fuses for visual and/or remote blown fuse indication. 600 Volts 1.6 amps .
Mersen

AJT1-6/10

Alternate Item Number: AJT1-6/10

UPC: 782001962753

Documents & Media
Technical DrawingLine DrawingSpecification Sheet

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

The Mersen Amp-Trap 2000 AJT1-6/10 time-delay fuse delivers IEC Type 2 (No Damage) overcurrent protection for industrial electrical systems, ensuring compliance with safety standards while optimizing space and performance. This 600V, 1.6A fuse combines current-limiting capabilities with time-delay characteristics to handle motor in-rush currents effectively, eliminating nuisance trips and reducing downtime. Its compact Class J design requires only half the mounting space of traditional 600V UL Class RK fuses, making it ideal for space-constrained installations in manufacturing plants, commercial buildings, and infrastructure projects. Designed for versatility, the AJT1-6/10 provides reliable protection across a wide range of loads, including motors, transformers, and general-purpose industrial equipment. The time-delay feature ensures seamless operation during temporary overloads, such as startup surges, while the current-limiting design minimizes fault currents to protect downstream components. With a 300kA interrupting rating (self-certified, UL witnessed), this fuse exceeds standard requirements for arc flash energy reduction and system reliability. Available in blade-type configurations (70 to 600A), the AJT series supports optional SmartSpot visual blown fuse indicators and Microswitches for both visual and remote monitoring, enhancing system reliability and maintenance efficiency. The fiberglass body ensures dimensional stability in harsh industrial environments, while high-grade silica filler guarantees fast arc quenching. Unique Class J dimensions prevent replacement errors, and metal-embossed date/catalog numbers ensure traceability. Certified to UL 248-8, CSA C22.2 No. 248.8, and IEC 60269-2-1, the AJT1-6/10 meets global standards for industrial electrical protection.
  • IEC Type 2 (No Damage) protection for main, feeder, and branch circuits
  • Time-delay design handles motor in-rush currents without nuisance trips
  • 300kA interrupting rating (self-certified, UL witnessed) for superior arc flash reduction
  • Compact Class J dimensions require half the mounting space of UL Class RK fuses
  • Optional SmartSpot visual blown fuse indicator (70-600A models) for monitoring
  • Fiberglass body with silica filler for stability and fast arc quenching in harsh environments
  • UL 248-8, CSA C22.2 No. 248.8, and IEC 60269-2-1 certified

Specifications

AC Voltage Rating
600 V
Amperage Rating
1.6 A
Application
Motor Circuits Mains Feeders Branch Circuits Lighting Heaters Transformers Control Panels Circuit Breaker Back-up Bus Duct Load Centers
Application
Motor circuits Mains Feeders Branch circuits Lighting, heating & general loads Transformers Control panels Circuit breaker back-up Bus duct Load centers
Body Material
GMG
Brand Name
Ferraz Shawmut
Class
Class J
Connection
Ferrule
Connection Material
Tin-Plated Copper
Current Rating
1.6 A
Interrupt Rating
200 kA
Mounting
Clip
Series
Amp-Trap 2000
Size
2.25 x 0.81 in
Size
57.15 x 20.65 mm
Special Features
Solid-state SmartSpot indicator Time-delay for motor starting and transformer inrush 300kA interrupting rating, self-certified (UL witnessed) Extremely current-limiting for low peak let-thru current Most current-limiting UL class fuse Small footprint requires less mounting space and allows smaller, more economical fuse blocks Easy 2-to-1 selectivity for prevention of nuisance shutdowns Unique Class J dimensions prevent replacement errors High-visibility orange label gives instant recognition Metal embossed date and catalog number for traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings High-grade silica filler ensures fast arc quenching Optional EI blown fuse indicator/switch available
Special Features
Non-indicating or solid state SmartSpot visual blown fuse indicator Time-delay for motor starting and transformer inrush Self Certified 700VAC, 15-600A range, 100kA IR 300kA interrupting rating - self-certified, UL witnessed tests Extremely current-limiting for low peak let-thru current Most current-limiting UL class fuse Recommended for Arc Flash energy reduction Small footprint requires less mounting space and allows smaller, more economical fuse blocks Easy 2-to-1 selectivity for prevention of nuisance shutdowns Unique Class J dimensions prevent replacement errors High-visibility orange label gives instant brand recognition Metal-embossed date and catalog number for traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings High-grade silica filler ensures fast arc quenching Optional EI indicator/switch mount for AJT70 to 600 open fuse indication
Standard
UL Listed to Standard 248-8, File E2137 DC Listed to UL Standard 248 CSA Certified to Standard C22.2, No. 248.8 IEC 269-2-1
Standard
AJT (1-600): UL listed to standard 248-8 File E2137 DC listed to UL standard 248 CSA certified to standard C22.2 No. 248.8 IEC 60269-2-1 AJT (70-600) EI: UL listed DC tested to UL standard 248 Self Certified 700VAC, 15-600A range
Sub Brand
Amp-Trap® 2000, SmartSpot®
Type
Class J
Type
North American Power Fuses
Voltage Rating
600 VAC
Package Dimensions (L x W x H)
2.25 IN x 0.813 IN x 0.813 IN
Package Dimensions (L x W x H)
5.715 cm x 20.6502 mm x 20.6502 mm
Package Weight (Imperial)
0.200 L
Package Weight (Metric)
0.091 kg
