Contact for Pricing
Minimum Qty: 1
Multiplier: 3
*Contact for lower quantities*
Overview
- 60A current rating with 600VAC/600VDC voltage rating
- Time-delay design prevents nuisance tripping during temporary surges
- Reduced-rated fuse eliminates need for additional accessories
- Larger body improves heat dissipation and durability
- UL Listed and manufactured in France
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 60 A |
Application | Motors Safety switches Transformers Branch circuit protection Disconnects Control panels All general-purpose circuits |
Body Material | PolyTube |
Class | Class RK1 |
Connection | Blade |
Connection Material | Tin-Plated Copper |
Connection Type | Blade |
Current Rating | 60 A |
Interrupt Rating | 200 kA |
Mounting | Clip |
Series | Amp-Trap 2000® |
Size | 7.88 x 1.31 in |
Size | 200.152 x 33.274 mm |
Size | 7.88 x 1.31;200.152 x 33.274 in;mm |
Special Features | Replaces traditional temporary-use only Fuse Reducer accessories Time-delay for motor starting and transformer inrush currents without nuisance opening 600VAC & 600VDC dual rated 300kA interrupting rating - self-certified, UL witnessed tests Extremely current-limiting for low peak let-thru current Recommended for Arc Flash energy reduction Easy 2-to-1 selectivity for prevention of nuisance shut downs and “black outs” Rejection-style design prevents replacement errors (when used with recommended fuse blocks) High-visibility orange label gives instant brand recognition Reduced inventory by taking the place of lower-rated Class RK1 fuses and associated Fuse Reducer accessories Metal-embossed date and catalog number for easier traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings |
Standard | UL Special Purpose Listed to 248-12 DC listed to UL standard 248 CSA certified to standard C22.2 No. 248.12 |
Type | Class RK1 |
Voltage Rating | 600 VAC/VDC |
Package Dimensions (L x W x H) | 7.88 in x 1.31 in x 1.31 in |
Package Dimensions (L x W x H) | 200.152 mm x 33.274 mm x 33.274 mm |
Package Weight (Imperial) | 0.550 lb |
Package Weight (Metric) | 0.249 kg |
