Overview
- Class RK1 time-delay ferrule fuse rated 25A at 600VAC/VDC
- IEC Type 2 "no damage" protection for mains, feeders, and branch circuits
- Rapid fault interruption to protect motor starters and switches
- Time-delay design accommodates motor in-rush currents
- Direct replacement for 600V Class H, K, or RK5 fuses
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 25 A |
Application | Motors Safety switches Transformers Branch circuit protection Disconnects Control panels All general-purpose circuits |
Body Material | PolyTube |
Brand Name | Mersen |
Class | Class RK1 |
Connection | Ferrule |
Connection Material | Tin-Plated Copper |
Connection Type | Ferrule |
Current Rating | 25 A |
Interrupt Rating | 200 kA |
Mounting | Clip |
Nema Rating | Class RK1 |
Series | Amp-Trap 2000® A6D-R |
Series | A6D-R |
Size | 5 x 0.81 in |
Size | 127 x 20.574 mm |
Size | 5 x 0.81;127 x 20.574 in;mm |
Special Features | Non-indicating or Solid state SmartSpot visual blown fuse indicator Time-delay for motor starting and transformer inrush currents without nuisance opening 600VAC & 600VDC dual rated 300kA interrupting rating - self-certified, UL witnessed tests Extremely current-limiting for low peak let-thru current Recommended for Arc Flash energy reduction Easy 2-to-1 selectivity for prevention of nuisance shut downs and “black outs” Rejection-style design prevents replacement errors (when used with recommended fuse blocks) High-visibility orange label gives instant brand recognition Reduced inventory by taking the place of class RK5, K, and H fuses Metal-embossed date and catalog number for easier traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings |
Standard | UL listed to standard 248-12 File E2137 DC listed to UL standard 248 CSA certified to standard C22.2 No. 248.12 |
Sub Brand | Amp-Trap 2000® |
Type | Class RK1 |
Voltage Rating | 600VAC/600VDC |
Voltage Rating | 600 VAC/VDC |
Package Dimensions (L x W x H) | 5 in x 0.81 in x 0.81 in |
Package Dimensions (L x W x H) | 127 mm x 20.574 mm x 20.574 mm |
Package Weight (Imperial) | 0.146 lb |
Package Weight (Metric) | 0.066 kg |
