Mersen A13X2-2 - A13X Amp-trap Form 101 Semiconductor Protection fuses were designed for the specific protection of diodes and other semiconductor devices rated 130VAC. The A13X product line's compact design is perfect for those applications that have limitations on available space. 130 Volts 2 Amps type 2 connection.
Mersen

A13X2-2

Alternate Item Number: 782001940027

UPC: 782001940027

Contact for Pricing

Overview

The Mersen A13X2-2, part of the esteemed Amp-trap Form 101 series, is a critical component engineered for the precise protection of sensitive semiconductor devices. Rated for 130VAC and a current of 2 Amps, this fuse is specifically designed to safeguard diodes, SCRs, and other power electronic components from damaging overcurrents and short circuits. Its compact form factor is a significant advantage in applications where space is at a premium, allowing for integration into densely populated control panels and equipment without compromising performance or safety. This fuse employs a Type 2 connection, ensuring a secure and reliable electrical interface essential for high-reliability industrial systems. The A13X series from Mersen is recognized for its fast-acting characteristics, a crucial attribute when protecting semiconductor devices that are particularly vulnerable to rapid current surges. By rapidly interrupting fault currents, the A13X2-2 minimizes the thermal stress on the protected semiconductor, thereby extending its operational lifespan and preventing catastrophic failures. Industries such as industrial automation, power conversion, renewable energy systems (including solar inverters and wind turbines), and motor control heavily rely on the robust protection offered by fuses like the Mersen A13X2-2. Its 130VAC rating makes it suitable for a wide array of low-voltage DC and AC power supplies and distribution systems. The selection of an appropriate semiconductor protection fuse is paramount; professionals choose Mersen due to their long-standing reputation for quality, reliability, and innovation in electrical protection solutions. Key features and benefits of the Mersen A13X2-2 include: * **Specialized Semiconductor Protection:** Specifically designed to protect diodes, SCRs, and other sensitive semiconductor devices. * **Compact Design:** Ideal for space-constrained applications, facilitating easier integration into control cabinets and equipment. * **Fast-Acting Performance:** Rapidly interrupts fault currents to minimize damage to protected components. * **130VAC Voltage Rating:** Suitable for a broad range of low-voltage power systems. * **2 Amp Current Rating:** Provides precise overcurrent protection for specific circuit requirements. * **Type 2 Connection:** Ensures a secure and reliable electrical connection. When specifying protection for critical semiconductor circuits, the Mersen A13X2-2 Amp-trap Form 101 fuse offers a dependable and efficient solution. Its meticulous design and adherence to high manufacturing standards underscore Mersen's commitment to providing advanced electrical safety components that meet the rigorous demands of modern industrial environments. Trust Mersen for unparalleled protection of your valuable electronic assets.
  • Mersen A13X2-2 Amp-trap Form 101 Semiconductor Protection Fuse
  • Designed for diodes and other semiconductor devices
  • 130 VAC voltage rating
  • 2 Amp current rating
  • Type 2 connection for secure integration

Specifications

Amperage Rating
2 A
Application
Protection of drives, UPS, Rectifiers and other equipment of 130 volts or less
Brand Name
Ferraz Shawmut
Connection
Ferrule
Connection Type
Type 2
Current Rating
2 A
Mounting
Clip
Series
A13X
Standard
UL Recognized Component Guide JFHR8, File E60314 Some Ratings RoHS Compliant
Type
North American Round Style
Voltage Rating
130 VAC
Package Dimensions (L x W x H)
1.5 IN x 0.41 IN x 0.41 IN
Package Dimensions (L x W x H)
3.81 cm x 10.414 mm x 10.414 mm
Package Weight (Imperial)
0.012 L
Package Weight (Metric)
0.005 kg
