Mersen A051F1DHR0-9R - Back-Up R-Rated Medium Voltage Fuse 5080VAC 9R Mounting: Ferrule Style: DHR0 Visual Indicator Amp-Trap®
Mersen

A051F1DHR0-9R

Alternate Item Number: A051F1DHR0-9R

UPC: 782001499822

Documents & Media
Line Drawing

Contact for Pricing

Minimum Qty: 3

Multiplier: 1

*Contact for lower quantities*

Overview

The Mersen Amp-Trap® A051F1DHR0-9R is a current-limiting, high-interrupting medium voltage fuse designed for short circuit protection in motor and motor controller applications. Rated at 5080VAC and 9R, this back-up fuse provides a minimum interrupting rating of 50 kA RMS symmetrical, ensuring reliable performance in medium voltage systems up to 5080 volts AC. The DHR0 size fuse features a ferrule mounting style with a 3-inch diameter barrel and spring-reinforced clips for secure installation, accommodating conductor sizes from 1/0 AWG to 4/0 AWG. These fuses are engineered for use in combination motor starters, where coordination with overload relays is required to protect motors from short circuits while allowing normal overload conditions without nuisance tripping. The Amp-Trap® series is manufactured in the US and includes a visual indicator for easy status verification, with a bright red indicator that activates upon fuse operation. Typical applications include medium voltage motors in industrial, commercial, and utility settings where high fault currents are a concern, such as in pumps, fans, compressors, and conveyors. The 9R rating indicates the fuse's interrupting capacity and coordination class, making it suitable for protecting motors up to the specified voltage and current levels while maintaining selective coordination with downstream protective devices. The fuse meets or exceeds industry standards including UL 198M and ANSI C37.46, ensuring compliance with safety and performance requirements. Always follow the motor starter manufacturer's specified fuse size for proper coordination and system protection, as improper selection can lead to equipment damage or safety hazards. The A051F1DHR0-9R is part of Mersen's comprehensive medium voltage fuse portfolio, which is designed to provide superior protection and reliability in demanding electrical environments.
  • 5080VAC voltage rating for medium voltage applications
  • 9R interrupting rating for short circuit protection in motors
  • DHR0 size with ferrule mounting for secure installation
  • Visual indicator for easy status verification
  • Designed for coordination with overload relays in motor starters

Specifications

AC Voltage Rating
5080 V
Application
Short circuit protection of medium voltage motors and motor controllers
Body Material
Epoxy
Brand Name
Mersen
Color
Red
Connection
Ferrule
Connection Material
Silver-Plated Copper
Connection Type
Ferrule
Current Rating
9R
Frequency
60 Hz
Interrupt Rating
50 kA
Material
Metal (ferrule), Ceramic/Glass (barrel)
Mounting
Clip
Mounting Type
Ferrule mount with spring-reinforced clips
Series
Amp-Trap®
Size
15.88 x 3 in
Size
403.352 x 76.2 mm
Size
DHR0 (3-inch diameter barrel)
Special Features
The Amp-Trap and 9F60 R-Rated fuses are UL Recognized Ferrule mounting for standard clips and interchangeability with other brands of fuses Current-limiting for superior equipment protection Metal embossed catalog number and manufacturing date for lasting identification Hookeye for non load-break isolation by hookstick: On the 4.8kV an optional hookeye mounted in the factory is available On all other 3" barrels if a hookeye is required, use the operating eye 9F61AAW612 Blown-fuse indicator to give positive identification of open fuse Amp trap: 3" Barrel 2 lb tripped force - 0.50 Inch 9F60: 0.125 lb tripped force – 0.20 Inch
Standard
Amp-Trap: UL File E93367 9F60: UL File E191980
Sub Brand
Amp-Trap®
Type
Back-Up R-Rated Ferrule Mount Fuses for Motor Protection
Type Of Indicators
Visual Indicator
Voltage Rating
5080 VAC
Package Dimensions (L x W x H)
15.88 in x 3 in x 4.55 in
Package Dimensions (L x W x H)
403.352 mm x 76.2 mm x 115.57 mm
Package Weight (Imperial)
11.200 lb
Package Weight (Metric)
5.080 kg
