Littelfuse T7900.0030 - Electronic Potentiometer. 230V AC. The T7900 Electronic Potentiometer is typically used as an interface between a unit that provides increase/decrease contacts signals and electronic speed governors or voltage regulators (AVR) controlled by analogue voltage or current signals. The T7900 works much like a conventional motorized potentiometer (e.g. the E7800). However, instead of a variable resistance, the T7900 provides a variable voltage (e.g. -5 to +5 VDC), current (e.g. 4-20 mA) or a pulse width modulated signal (PWM). The voltage and current range is programmable. The PWM output provides a 500 Hz signal with programmable duty cycle. The analogue outputs are galvanically isolated.
Littelfuse

T7900.0030

UPC: 079458963502

Documents & Media
Brochure

Contact for Pricing

Overview

The Littelfuse T7900.0030 Electronic Potentiometer is a high-performance, programmable interface solution engineered for precise control of electronic speed governors and automatic voltage regulators (AVRs) in industrial power systems. Unlike conventional motorized potentiometers, the T7900 delivers advanced signal conditioning capabilities, providing variable voltage (-5 to +5 VDC), current (4-20 mA), or pulse width modulated (PWM) outputs at 500 Hz—all with galvanic isolation for enhanced reliability and noise immunity. This versatility makes it an ideal choice for applications requiring seamless integration with modern electronic controllers, where traditional resistive potentiometers fall short in performance and flexibility. Designed for engineers and system integrators working in power generation, industrial automation, and process control, the T7900 serves as a critical interface between digital or relay-based control systems and analog-controlled governors or AVRs. Its programmable output ranges allow for easy adaptation to diverse control requirements, eliminating the need for additional signal conditioning hardware. The galvanically isolated outputs ensure robust operation in electrically noisy environments, such as motor control centers, generator sets, and renewable energy systems, where signal integrity is paramount. Key applications include: - **Generator voltage regulation**: Precise control of AVRs in diesel, gas, or hydroelectric generators to maintain stable output voltage under varying load conditions. - **Speed governor control**: Interface with electronic or mechanical governors to adjust engine speed dynamically, optimizing fuel efficiency and performance in co-generation or parallel operation setups. - **Industrial motor control**: Integration with variable frequency drives (VFDs) or servo controllers requiring analog voltage/current inputs for speed or torque adjustments. - **Process automation**: Signal conditioning for PID controllers, PLCs, or distributed control systems (DCS) where analog output signals are required for actuator control. - **Renewable energy systems**: Compatibility with solar inverters, wind turbine controllers, and battery management systems (BMS) that rely on analog signals for power regulation. The T7900’s PWM output, operating at 500 Hz with a programmable duty cycle, provides a high-resolution alternative to analog signals, making it suitable for applications demanding rapid response times or compatibility with digital control systems. Its compact, industrial-grade design ensures durability in harsh environments, with mounting options for DIN rails or panel installation. Engineers benefit from Littelfuse’s reputation for reliability, backed by decades of expertise in protection and control solutions for critical power systems. Selecting the right electronic potentiometer involves evaluating output compatibility, isolation requirements, and programmability. The T7900 addresses these needs with user-configurable voltage/current ranges, reducing engineering time and minimizing the risk of signal mismatch. For systems already utilizing Littelfuse’s E7800 motorized potentiometer, the T7900 offers a seamless upgrade path to digital control without redesigning existing infrastructure. Its compliance with industrial standards and broad compatibility with third-party governors and AVRs further solidify its position as a go-to solution for modern power management challenges. Backed by Littelfuse’s global support network and adherence to stringent quality protocols, the T7900.0030 Electronic Potentiometer delivers the precision, flexibility, and reliability demanded by today’s industrial automation and power generation professionals.
  • Programmable outputs: -5 to +5 VDC, 4-20 mA, or 500 Hz PWM for versatile control
  • Galvanically isolated analog outputs for noise immunity in industrial environments
  • Seamless interface between digital/relay signals and electronic governors or AVRs
  • Compact, industrial-grade design with DIN rail or panel mounting options
  • Compatible with generators, motors, VFDs, and renewable energy systems

Specifications

Application
Industrial
Brand Name
Littelfuse
Current Rating
4-20 mA
Frequency
500 Hz
Series
T7900
Special Features
High Quality
Sub Brand
Relay Series
Type
Protection Relays and Controls
Voltage Rating
230 V AC
Voltage Rating
230V AC, -5 to +5 VDC
