Littelfuse H313.300P - SLO-BLO GLASS FUSE H-PACK .300A. The 3AG Slo-Blo® fuse solves a broad range of application requirements while offering reliable performance and costeffective circuit protection. Features: 313 and 315 series fuses have time-delayed in the overload range, which provides superior protection inductive loads such as motors, transformers, and solenoids. 3AG indicating fuses instantly identify themselves upon opening by showing a discoloration of their glass bodies. Guesswork and time-consuming circuit testing is eliminated. This unique design offers the same quality performance characteristics as the standard 3AG fuse design.
Littelfuse

H313.300P

Alternate Item Number: 0313.300HXP

UPC: 079458922707

Documents & Media
BrochureTechnical BulletinTechnical DrawingSpecification Sheet

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Overview

The Littelfuse H313.300P Slo-Blo® Glass Fuse (SKU: H313.300P) from the 3AG series delivers superior circuit protection for industrial applications requiring reliable performance under inductive load conditions. Designed to meet the demanding requirements of motors, transformers, solenoids, and other inductive loads, this time-delayed fuse provides a cost-effective solution without compromising on safety or durability. The 313 and 315 series fuses feature a time-delayed response in the overload range, allowing them to handle temporary current surges common in startup and transient conditions while ensuring rapid interruption during fault conditions. This makes them particularly well-suited for applications where nuisance tripping must be minimized, such as in HVAC systems, industrial machinery, and power distribution networks. A standout feature of the H313.300P is its 3AG indicating design, which provides visual confirmation of fuse operation. Upon opening, the glass body discolors, instantly signaling that the fuse has blown. This eliminates the need for time-consuming circuit testing or multimeter checks, significantly reducing troubleshooting time and improving operational efficiency. For maintenance teams and engineers, this feature translates to faster diagnostics, reduced downtime, and lower labor costs associated with fault identification. The indicating capability is especially valuable in critical applications where rapid response is essential to prevent equipment damage or safety hazards. The H313.300P Slo-Blo Glass Fuse is engineered to meet the rigorous demands of industrial environments, where reliability and longevity are paramount. Littelfuse, a global leader in circuit protection solutions, has designed this fuse to deliver consistent performance across a wide range of operating conditions. The 3AG form factor ensures compatibility with standard fuse blocks and holders, making it a versatile choice for retrofitting existing systems or designing new installations. Whether used in control panels, power supplies, or motor starters, this fuse provides a dependable barrier against overcurrent events, protecting sensitive components and extending the lifespan of connected equipment. Selecting the right fuse for an application involves balancing response time, current rating, and environmental factors. The H313.300P’s 0.300A rating makes it ideal for protecting low-to-moderate current circuits, such as those found in control circuits, relays, and small motors. Its time-delayed characteristic ensures it can withstand brief overloads without interrupting operation, while still providing fast-acting protection during sustained faults. This balance is critical in applications involving inductive loads, where inrush currents can be significantly higher than steady-state operating currents. By choosing a Slo-Blo fuse, engineers can avoid unnecessary interruptions while maintaining robust protection against short circuits and ground faults. Installation of the H313.300P is straightforward, requiring no specialized tools or procedures. The fuse fits standard 3AG fuse holders, which are widely available and compatible with most industrial enclosures. When installing, professionals should ensure proper seating to avoid poor contact, which can lead to overheating or nuisance tripping. Regular inspection of the fuse and holder is recommended to confirm integrity, particularly in harsh or vibration-prone environments. For applications with high vibration or temperature fluctuations, Littelfuse offers additional accessories such as fuse clips and holders designed to enhance stability and performance. Littelfuse’s reputation as a trusted provider of circuit protection solutions is built on decades of innovation and reliability. The company’s Slo-Blo series, including the H313.300P, is a testament to its commitment to delivering products that meet the evolving needs of industrial, commercial, and residential markets. With a global distribution network and a focus on quality assurance, Littelfuse ensures that customers receive consistent, high-performance fuses that adhere to industry standards such as UL, CSA, and IEC. For engineers and procurement teams seeking a dependable, cost-effective fuse solution for inductive load protection, the Littelfuse H313.300P Slo-Blo Glass Fuse is an excellent choice.
  • Time-delayed response for superior protection of inductive loads (motors, transformers, solenoids)
  • 3AG indicating design visibly discolors upon opening for quick fault identification
  • 0.300A rating ideal for low-to-moderate current circuit protection
  • Cost-effective solution with reliable performance in industrial applications
  • Compatible with standard 3AG fuse holders for easy installation and retrofitting

Specifications

Amperage Rating
.300 Amps
Application
electronic equipment & appliances
Brand Name
Littelfuse
Special Features
Slo-Blo
Standard
UL Standard 248-14
Sub Brand
313 Series
Type
3AG Slo-Blo
