Overview
- Single-phase buck-boost transformer for voltage adjustment
- 120x240 VAC primary voltage, 12x24 VAC secondary voltage
- Welded core construction with high-quality silicon steel and copper wire
- Encapsulated with silica sand and resin for durability
- UL Listed (E50394) and CSA Certified (LR3902)
Specifications
Application | General purpose for raising supply voltage caused by line drop or equipment demand on the distribution system, or lower voltage caused by increased system voltages due to supply line adjustments |
Enclosure | NQ4-N3R - Indoor or Outdoor |
Frequency Rating | 50/60 HZ |
Height | 11.75 in |
Length | 6.25 IN |
Mounting | Wall mount |
Special Features | Encapsulated transformers can be used to buck and boost voltage in single and three phase applications where supply voltages are frequently above or below nominal. These transformers can also be used in low voltage transformer application. |
Standard | CSA, UL, Class 1 Div II |
Temperature Rating | Typical 30 Average/ 40 Maximum Deg C |
Type | Transformer > Dry Type > Buck-Boost |
Width | 7.06 in |
Package Dimensions (L x W x H) | 6.25 IN x 7.06 IN x 11.75 IN |
Package Dimensions (L x W x H) | 158.75 mm x 179.34 mm x 298.45 mm |
Package Weight (Imperial) | 46.000 L |
Package Weight (Metric) | 20.861 kg |
