EKS Engel 0410001005353EV10-00 - EL100-2M/6x10/100TX-2x100FX-SM-SC IE Switch (Managed/Ring/Extended)
EKS Engel

0410001005353EV10-00

Alternate Item Number: 10001705

Contact for Pricing

Overview

The EKS Engel 0410001005353EV10-00 is a managed industrial Ethernet switch from the EL100 series, engineered for mission-critical network environments. This model features 6x 10/100TX copper ports for standard Ethernet connectivity and 2x 100FX single-mode fiber optic ports with SC connectors, providing extended reach and immunity to electromagnetic interference. Designed for robust connectivity, it supports ring topology for network redundancy and resilience, ensuring maximum uptime in demanding industrial applications. Its extended environmental capabilities allow for reliable operation in challenging conditions typical of manufacturing, process control, and industrial automation sectors. The managed architecture offers advanced network control and monitoring features, crucial for maintaining network integrity and performance in complex industrial networks. This switch is an ideal solution for building reliable and high-availability industrial communication infrastructures.
  • 6x 10/100TX Ethernet ports
  • 2x 100FX single-mode fiber optic ports (SC connector)
  • Managed network switch with ring topology support
  • Designed for industrial environments
  • Extended environmental capabilities for reliability
