ABB - Low Voltage Drives
MS116-16
Alternate Item Number: 1SAM250000R1011
Contact for Pricing
Overview
The ABB MS116-16 is a manual motor starter designed for thermal and electromagnetic protection of three-phase and single-phase motors up to 7.5 kW at 400V AC. Part of ABB’s MS116 series (SKU: MS116-16), this compact 45mm-wide unit delivers reliable motor protection with an adjustable thermal setting range of 10.0–16.0 A and a rated instantaneous short-circuit current setting (li) of 16 kA at 400V AC. It includes a built-in disconnect function, temperature compensation, and a trip-free mechanism for enhanced safety. The rotary handle provides clear switch position indication, ensuring easy operation and maintenance. Suitable for AC-3 and AC-3e applications, the MS116-16 is ideal for industrial environments requiring precise motor control and protection. Optional accessories such as auxiliary contacts, signaling contacts, undervoltage releases, and shunt trips are available for expanded functionality. Manufactured in Germany, this starter is part of a range supporting motor protection up to 15 kW (400V) / 32 A in a 45mm width, ensuring compatibility with broader motor control systems.
- Thermal and electromagnetic protection for 3-phase and single-phase motors up to 7.5 kW at 400V AC
- Adjustable thermal setting range: 10.0–16.0 A with 16 kA rated instantaneous short-circuit current (li)
- Built-in disconnect function, temperature compensation, and trip-free mechanism for safety
- Rotary handle with clear switch position indication; 45mm-wide, 3-pole design
- Suitable for AC-3 and AC-3e applications; compatible with optional accessories (auxiliary contacts, undervoltage releases, etc.)
- Compatible with auxiliary contacts, undervoltage releases, and shunt trips
- Manufactured in Germany by ABB Low Voltage Drives
Specifications
Current Rating | 10-16 A |
Current Rating | 10.0 to 16.0 A |
Poles | 3P |
Poles | 3-Phase |
Series | MS116 |
Size | 45 mm |
Voltage Rating | 400 V AC |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
Frequently Asked Questions
What is the thermal setting range for the MS116-16?
The thermal setting range for the MS116-16 is 10.0 to 16.0 A.
What is the rated short-circuit current setting (li) at 400V AC?
The rated instantaneous short-circuit current setting (li) is 16 kA at 400V AC.
What motor power rating does the MS116-16 support at 400V AC?
The MS116-16 supports motors up to 7.5 kW at 400V AC.
Does the MS116-16 include a disconnect function?
Yes, the MS116-16 features a built-in disconnect function.
What is the width of the MS116-16 manual motor starter?
The MS116-16 has a compact width of 45 mm.
Is the MS116-16 suitable for single-phase motors?
Yes, the MS116-16 is suitable for both three-phase and single-phase motors.
What accessories are available for the MS116-16?
Accessories include auxiliary contacts, signaling contacts, undervoltage releases, and shunt trips.
