ABB - Low Voltage Drives
ACS355-03U-23A1-4+J404+K466+N827
Alternate Item Number: 3AUA0000176471
UPC: 662348033357
Documents & Media
Contact for Pricing
Overview
The ABB ACS355-03U-23A1-4+J404+K466+N827 is a 10 HP, 480VAC cabinet-mounted machinery drive designed for industrial applications. This drive delivers 23.1A output current and supports 3-phase input/output within a 380-480VAC range. Its compact R3 frame measures 9.29 in x 6.65 in x 6.65 in and weighs 5.5 lbs, enabling easy integration into existing control panels. The drive includes built-in Ethernet/IP, Modbus TCP, and PROFINET adapters for seamless industrial network connectivity. Certified to UL TYPE OPEN (IP20) standards, it ensures safe operation in open cabinet environments. Ideal for solar pump applications, the ACS355 series provides reliable variable speed control with minimal footprint. The drive’s 3-phase design supports balanced power distribution and efficient motor operation. ABB’s ACS355 series is widely deployed in machinery automation, offering proven reliability in industrial settings.
- 10 HP, 480VAC output with 23.1A current rating
- 3-phase input/output for balanced power distribution
- Built-in Ethernet/IP, Modbus TCP, PROFINET adapters for industrial networking
- Compact R3 frame (9.29 in x 6.65 in x 6.65 in) and 5.5 lbs weight
- UL TYPE OPEN (IP20) certified for open cabinet installations
Specifications
Connection Type | 3-Phase Input/Output |
Current Rating | 23.1 A |
IP Rating | IP20 |
Mounting Type | Cabinet-mounted |
Nema Rating | OPEN |
Nema Rating | Type OPEN |
Poles | 3-Phase |
Series | ACS355 |
Size | 9.29 in x 6.65 in x 6.65 in |
Size | R3 |
Voltage Rating | 480 VAC |
Package Dimensions (L x W x H) | 13 in x 8 in x 8.5 in |
Package Dimensions (L x W x H) | 33.02 cm x 20.32 cm x 21.59 cm |
Package Weight (Imperial) | 11.000 L |
Package Weight (Metric) | 4.990 kg |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
