ABB - Low Voltage Drives
ACS355-03U-03A3-4+B063+C169+F278+N828
Alternate Item Number: 3AUA0000177456
UPC: 662348015209
Documents & Media
Contact for Pricing
Overview
The ABB ACS355-03U-03A3-4+B063+C169+F278+N828 is a 1.5 HP, 3-phase industrial machinery drive designed for reliable operation in demanding environments. This wall-mounted unit features a 480 VAC voltage rating and an output current of 3.3 A, ensuring robust performance for various industrial applications. Its UL TYPE 4X (IP66) enclosure provides superior protection against dust, water, and corrosive substances, making it suitable for harsh conditions. The drive offers 3-phase input and 3-phase output for seamless integration into existing electrical systems. Key features include an advanced control panel for intuitive operation, low ambient start capability for reliable cold-weather performance, and a pressure compensation valve to maintain internal integrity in fluctuating environmental pressures. The frame size is R1, with product dimensions of 12.01 inches in height, 7.69 inches in width, and 11.06 inches in depth, and a weight of 16.98 lbs. This drive is ideal for applications requiring precise motor control and enhanced operational efficiency in industrial automation settings. The non-fusible service switch enhances safety during maintenance. Manufactured by ABB Low Voltage Drives, this drive is built for durability and ease of installation.
- 1.5 HP, 3-Phase, 480 VAC Machinery Drive
- UL TYPE 4X (IP66) Enclosure for Harsh Environments
- 3.3 A Output Current
- Wall-mounted design with advanced panel
- Low Ambient Start and Pressure Compensation Valve
Specifications
Package Dimensions (L x W x H) | 23 in x 10 in x 14 in |
Package Dimensions (L x W x H) | 58.42 cm x 25.4 cm x 35.56 cm |
Package Weight (Imperial) | 28.000 L |
Package Weight (Metric) | 12.701 kg |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
