ABB - Low Voltage Drives
ACS355-03U-01A2-4+B063+F278+K458+N828
Alternate Item Number: 3AUA0000177511
UPC: 662348009994
Documents & Media
Contact for Pricing
Overview
The ABB ACS355-03U-01A2-4+B063+F278+K458+N828 is a 0.5 HP, 3-phase machinery drive designed for industrial applications. Operating within a 380-480 VAC range, this unit delivers an output current of 1.2 A. Its UL TYPE 4X (IP66) rating ensures protection against dust and water ingress, making it suitable for harsh environments. The drive is wall-mounted and features an advanced panel for user interaction. Integrated Modbus RTU adapter facilitates communication with automation systems. Additional functionalities include low ambient start capability and a non-fusible service switch for operational safety. The physical dimensions are 12.01 x 7.69 x 11.06 inches, with a weight of 16.98 lbs. This ABB Low Voltage Drives product, frame size R1, is engineered for reliable motor control in machinery applications.
- 0.5 HP Motor Power
- 480 VAC, 3-Phase Input/Output
- 1.2 A Output Current
- UL TYPE 4X (IP66) Enclosure Rating
- Wall-mounted with Advanced Panel and Modbus RTU Adapter
Specifications
Connection Type | 3-Phase Input, 3-Phase Output |
Connection Type | 3-phase |
Connection Type | 3-Phase Input/Output |
Current Rating | 1.2 A |
IP Rating | IP66 |
Mounting Type | Wall-mounted |
Nema Rating | Type 4X |
Nema Rating | NEMA 4X |
Poles | 3 |
Poles | 3-Phase |
Series | ACS355 |
Size | 12.01 in x 7.69 in x 11.06 in |
Size | 12.01 x 7.69 x 11.06 in |
Voltage Rating | 480 VAC |
Voltage Rating | 380-480 VAC |
Voltage Rating | 380-480V |
Package Dimensions (L x W x H) | 23 in x 10 in x 14 in |
Package Dimensions (L x W x H) | 58.42 cm x 25.4 cm x 35.56 cm |
Package Weight (Imperial) | 28.000 L |
Package Weight (Metric) | 12.701 kg |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
