ABB - Installation Products UNY505-B - PVC Coated Explosion and Dust-Ignition Proof UNY Male Union, Pipe Size 1-1/2 Inch/41 Metric, 3 Piece, for Hazardous and Non-hazardous Locations, Overall Length 3.63 Inch/92.20 Millimeters, Overall Diameter 3.06 Inch/77.72 Millimeters, Electrogalvanized Steel, Light Blue
ABB - Installation Products

UNY505-B

UPC: 704508414122

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Overview

The ABB UNY505-B is a three-piece, PVC-coated male union designed for explosionproof and dust-ignitionproof applications in hazardous and non-hazardous locations. Manufactured by ABB Installation Products, this union is constructed from electrogalvanized steel with a light blue PVC coating, offering robust corrosion protection and maintaining grounding continuity for rigid conduit systems. It is specifically designed to connect rigid conduit to conduit fittings, junction boxes, control station enclosures, or other electrical component enclosures. The UNY505-B is UL 1203 listed, ensuring compliance with stringent safety standards for environments classified under NEC/CEC Class I, Division 1 & 2, Groups C, D; Class II, Division 1, Groups E, F, G; and Class III, Division 1 & 2. Its 1-1/2 inch (41 Metric) pipe size, 3.63 inch (92.20 mm) overall length, and 3.06 inch (77.72 mm) overall diameter make it suitable for a variety of industrial installations. The flexible PVC sealing sleeves contribute to corrosion protection of threaded connectors. This union is ideal for use in oil, gas, chemical, and other industries where explosion and dust ignition hazards are present, providing reliable and certified protection for electrical systems. The light blue finish enhances visibility and offers additional corrosion resistance. SKU: UNY505-B.
  • Explosionproof and Dust-Ignitionproof for hazardous locations (NEC/CEC Class I, Div 1&2, Groups C,D; Class II, Div 1, Groups E,F,G; Class III)
  • UL 1203 Listed for explosion protection
  • Durable PVC coating over electrogalvanized steel for corrosion resistance and grounding continuity
  • Three-piece design for secure conduit connection to fittings, boxes, and enclosures
  • 1-1/2 Inch (41 Metric) pipe size with 3.63" length and 3.06" diameter

Specifications

Application
To Connect Conduit to a Conduit Fitting, Junction Box, or Device Enclosure
Color
Light Blue
Length
3.63 in
Length
92.2 mm
Material
Steel
Material
Electrogalvanized Steel with PVC Coating
Material Quality
Steel
Outside Diameter
3.06 in
Outside Diameter
77.72 mm
Series
UNY
Size
1-1/2 Inch (41 Metric)
Special Features
Compact Design Which Permits Assembly with a Minimum of Clearance to Other Adjacent Conduit and/or Equipment
Standard
UL 1203, CSA
Trade Size
1-1/2 in , 41 mm
Type
Male Union
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
3.900 L
Package Weight (Metric)
1.769 kg
PVC Coated Explosion and Dust-Ignition Proof UNF Female Union, Pipe Size 1-1/2 Inch/41 Metric, 3 Piece, for Hazardous and Non-hazardous Locations, Overall Length 2.75 Inch/69.85 Millimeters, Overall Diameter 3.06 Inch/77.72 Millimeters, Electrogalvanized Steel, Light Blue
