ABB - Installation Products U 1 N 104 - Insulated Aluminum Service Entrance Compression Splices - Conductor A: Yellow, 1/0 ACSR, 1/0 Stranded, Conductor B: Orange, 4 ACSR, 2 Solid, 4 Stranded, For AL to AL or AL to CU Conductors. Splice only 2-1/8 inch x 37/64 inch Diameter. Splice with Sleeve and Caps 3-1/4 inch x 47/64 inch Diameter. Oil Stop. Installing Dies: CSA-22, 5/8, TU, BG.
ABB - Installation Products

U 1 N 104

UPC: 783786756445

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 500

Multiplier: 500

*Contact for lower quantities*

Overview

The ABB Installation Products U 1 N 104 Insulated Aluminum Service Entrance Compression Splice is engineered for reliable connections in electrical distribution systems. This splice is designed for joining aluminum to aluminum or aluminum to copper conductors, offering versatility for various applications. The U 1 N 104 features a yellow conductor termination for Conductor A, specified as 1/0 ACSR or 1/0 Stranded aluminum. Conductor B is indicated by an orange termination, accommodating 4 ACSR, 2 Solid, or 4 Stranded aluminum conductors. The splice itself measures 2-1/8 inches in length with a 37/64 inch diameter. When equipped with its sleeve and caps, the overall dimensions increase to 3-1/4 inches in length and 47/64 inch diameter, providing robust protection and strain relief. A key feature of this splice is its 'Oil Stop' design, which prevents the migration of insulating oils, ensuring the integrity of the connection and preventing potential failures. Installation of the U 1 N 104 requires specific tooling. The recommended installing dies include CSA-22, 5/8, TU, and BG, ensuring a secure and permanent compression connection. This product, with SKU U 1 N 104, is a critical component for service entrance applications where dependable conductor joining is paramount. Its construction from aluminum ensures excellent conductivity and corrosion resistance, suitable for outdoor and exposed environments. The insulated design provides an additional layer of safety during installation and operation. ABB's commitment to quality in their Installation Products division is evident in the robust design and material selection of the U 1 N 104 splice, making it a trusted choice for utility and industrial electrical contractors.
  • Insulated Aluminum Service Entrance Compression Splice
  • Accommodates AL to AL or AL to CU conductors
  • Conductor A: Yellow, 1/0 ACSR, 1/0 Stranded
  • Conductor B: Orange, 4 ACSR, 2 Solid, 4 Stranded
  • Features Oil Stop design for connection integrity

Specifications

Color
Yellow/Orange
Conductor Range
Side A: #1 SOL , 1/0 STR , 1/0(6/1) ACSR Side B: #2 SOL , #4(6/1) ACSR
Connection
Compression
Insulation
Insulated
Material
Aluminum
Number Of Conductors
2
Size
3-1/4 inches long
Special Features
Prefilled with Oxide Inhibitor, Prevents oxidation and keeps out moisture. Solid Center Stops. Easy cable insertion. All splices are marked with installation die codes and compression locations for easy identificaton and installation
Standard
ANSI C119.4
Type
Compression Splice Service Entrance Insulated
Package Dimensions (L x W x H)
15.9 IN x 5.5 IN x 4.3 IN
Package Dimensions (L x W x H)
40.386 cm x 13.97 cm x 10.922 cm
Package Weight (Imperial)
0.0500 L
Package Weight (Metric)
0.0230 kg
