PTC 1000 R 750

This ABB splice is designed to reduce wire sizes from 1000 kcmil copper (CU) to 750 kcmil copper (CU).

The installation of the PTC 1000 R 750 requires installing dies 27 and P44PR.

The 1000 kcmil end is marked with white ink, and the 750 kcmil end is marked with black ink.

The solid center in this splice is designed to function as an oil stop, ensuring a secure and contained connection.

The ABB PTC 1000 R 750 splice is constructed from tin-plated copper.
