ABB - Installation Products LBD8800-G - PVC Coated Pulling Elbow, 90 Degree Bend, With Pressure-Sealing Sleeves Seal Connections, Pipe Size 3 Inch/78 Metric, Gray Iron, Dark Gray
ABB - Installation Products

LBD8800-G

UPC: 704508391614

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Overview

The ABB LBD8800-G is a 3-inch (78 metric) PVC-coated gray iron pulling elbow designed for 90-degree bends in industrial conduit systems. Manufactured by ABB Installation Products, this elbow facilitates straight wire pulls in either direction and acts as a pull outlet. It features a nominal 0.040" (40 mil) PVC coating bonded to the exterior, providing robust protection against moisture, chemicals, and abrasion, suitable for both indoor and outdoor use. The interior and exterior also have a nominal 0.002" (2 mil) blue urethane coating. Key features include pressure-sealing sleeves that ensure secure, leak-resistant connections, minimizing installation and maintenance costs. This LBD series elbow is intended for ordinary locations. Its dark gray finish blends with industrial infrastructure. The UNSPSC code is 39131717. This product is manufactured in the US. It is designed to make 90° bends in conduit systems while allowing straight wire pulls in either direction, acting as a pull outlet for conductors. The gray iron construction ensures durability, while the PVC coating offers superior corrosion resistance. Compatible with 3-inch (78 metric) trade size conduit systems, the LBD8800-G is an essential component for efficient cable routing and management in electrical installations. It is designed for use in ordinary locations, as indicated by the 'LBD' series designation.
  • 3-inch (78 metric) trade size PVC coated gray iron pulling elbow
  • 90-degree bend for efficient conduit routing and straight wire pulls
  • Nominal 0.040" (40 mil) exterior PVC coating for corrosion resistance
  • Pressure-sealing sleeves ensure secure, leak-resistant connections
  • Designed for ordinary locations (LBD series)

Specifications

Application
Installed at 90 Degree Bends in Rigid Conduit to Act as Pull Outlets for Conductors
Color
Gray
Color
Grey
Finish
PVC Coated
Material
Iron
Material Quality
Iron
Special Features
Pressure-Sealing Sleeves Seal Connections
Trade Size
3 in , 78 mm
Type
Conduit Pulling Elbow - Ordinary Locations
Package Dimensions (L x W x H)
25 IN x 16 IN x 16 IN
Package Dimensions (L x W x H)
63.5 cm x 40.64 cm x 40.64 cm
Package Weight (Imperial)
35.630 L
Package Weight (Metric)
16.162 kg
