Contact for Pricing
Overview
- 100 Amp current rating for high-power applications
- 3 Pole, 4 Wire configuration for versatile connections
- 30-480V voltage range supports diverse industrial power systems
- 60Hz frequency compatibility for standard industrial power
- Manufactured in the US by ABB Installation Products for quality assurance
Specifications
Amperage Rating | 100 A |
Application | Convention centers and areanas |
Connection Type | Female Connector |
Current Rating | 100 A |
Frequency | 60Hz |
Material | Cast Aluminum |
Material | Poly |
Material Quality | Cast Aluminum |
Number Of Poles | 3 |
Number Of Wires | 4 |
Poles | 3P4W |
Series | MaxGard |
Special Features | Waterproof construction provides environmental separation at the front of each device (they don't have to be connected together just to be called "watertight") |
Type | MaxGard Interconnection Systems |
Voltage Rating | 30-480 VAC |
Voltage Rating | 480 V |
Voltage Rating | 30-480V |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 6.650 L |
Package Weight (Metric) | 3.016 kg |
