Contact for Pricing
Overview
- 100A current rating with 600V voltage rating for heavy-duty applications
- 2-pole 3-wire (2P3W) configuration for single-phase systems with neutral
- Integrated angle adapter and back box for flexible installation and cable entry
- Rugged construction with IP-rated protection against dust and moisture
- Part of ABB MaxGard series, compliant with industry standards for industrial use
Specifications
Amperage Rating | 100 A |
Color | Grey |
Connection Type | Screw Terminal |
Current Rating | 100 A |
Material | Composite |
Mounting Type | Back Box with Angle Adapter |
Number Of Poles | 2 |
Number Of Wires | 3 |
Poles | 2P3W |
Series | MaxGard |
Voltage Rating | 600 V |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 4.500 L |
Package Weight (Metric) | 2.041 kg |
SP279
Wall Plate Screw, #6-32 size, Oval head, 1 in. length, White head color, Slotted drive type, Steel, Zinc Plated finish, 100 per pack
B118A
One-Gang Nail-On New Work Outlet Box, Volume 18 Cubic Inches, Length 3-3/4 Inches, Width 2-1/4 Inches, Depth 2-7/8 Inches, Color Blue, Material PVC, Mounting Means Captive Nails
A414
One-Gang Box Cover, Volume 8.1 Cubic Inches, 4 Inches Square, Raised 1-1/4 Inch, Color Blue, Material Non-Metallic
SC100RR
One-Gang Low-Voltage Old Work Bracket, Length 4.32 Inches, Width 2.52 Inches, Depth 1.66 Inches, Color Orange, Material Non-Metallic
A410R-CAR
One-Gang Box Cover, Volume 3.5 Cubic Inches, 4 Inches Square, Raised 1/2 Inch, Color Blue, Material Non-Metallic
B232ACP
Two-Gang Nail-On New Work Outlet Box, Volume 32 Cubic Inches, Length 3-3/4 Inches, Width 4 Inches, Depth 3 Inches, Color Blue, Material PVC, Mounting Means Captive Nails
IPLMD350-6
The Polaris IPLMD350-6 Multi-Tap Mountable Dual-Sided Entry Connector features 6 ports sized for 350 MCM - 6 AWG wires. Mounting holes on either side of the connector allow for direct mounting to troughs, panels or wireways with 1/4†bolts. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
