ABB - Installation Products 54919BEBTPH - Copper Blank Tongue Lug, Long Barrel, Peep Hole, Max 35kV, Wire Size 500 kcmil, Tin Plated, Die code 87, Die Color Code Brown
ABB - Installation Products

54919BEBTPH

UPC: 786209915917

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 5

Multiplier: 5

*Contact for lower quantities*

Overview

The ABB 54919BEBTPH Copper Blank Tongue Lug is a high-conductivity, tin-plated copper termination designed for secure electrical connections in high-voltage systems up to 35kV. Engineered for stranded copper conductors sized at 500 kcmil, this lug features a long barrel design that maximizes crimp count and enhances wire pull-out strength, ensuring long-term reliability in demanding industrial applications. The enclosed barrel design prevents corrosive contaminants from entering the connection, while the tin plating provides additional corrosion resistance in harsh environments. This lug is UL Listed and CSA Certified for 35kV applications and temperature-rated to 90°C when crimped with Panduit or specified competitor crimping tools and dies. The brown die color code (87) simplifies inventory management and ensures proper crimp die selection. With a stud hole size of 1.54 inches (39.1 mm) and a tongue width of 2.50 inches (63.5 mm), the 54919BEBTPH is ideal for power distribution systems, industrial machinery, and electrical infrastructure where durable, high-performance terminations are critical. Compatible with NEMA hole sizes and spacing, this lug is part of ABB’s Installation Products line, offering a dependable solution for critical electrical connections in power utilities, renewable energy systems, and heavy industrial applications.
  • Rated for 35kV applications with temperature rating of 90°C
  • Designed for 500 kcmil stranded copper conductors
  • Long barrel design maximizes crimp count and wire pull-out strength
  • Tin-plated copper construction resists corrosion in harsh environments
  • UL Listed and CSA Certified for high-voltage reliability
  • Brown die color code (87) for easy inventory and tool compatibility
  • Enclosed barrel prevents corrosive contaminants from entering the connection

Specifications

Cable Size
500 kcmil
Color
Blue
Color
Brown
Connection Type
Peep Hole
Insulation
None
Material
Copper
Material
Copper, Tin Plated
Number Of Holes
0
Size
500 kcmil
Type
Long Barrel
Voltage Rating
35 kV
Package Dimensions (L x W x H)
4 IN x 3 IN x 4 IN
Package Dimensions (L x W x H)
10.16 cm x 7.62 cm x 10.16 cm
Package Weight (Imperial)
0.550 L
Package Weight (Metric)
0.250 kg
